New Condition and Vertical Type Oil Fired Industrial Steam Boiler

Specifications

    Product Information

New Conditon and Vertical Type Oil Fired Industrial Steam Boiler:

It is the kind of horizontal, ready package, internal fired and three-pass fire tube boiler.  It adopts the offset furnace and wet-back structure, with high temperature gas washing the second and the third return stoke successively and then discharged into the air from the smoke room by the chimney.

    The boiler is equipped with movable forward and backward cover, making the boilers' examination and maintenance convenient and also equipped with a burner of good technological performance, employing those advanced techniques such as the automatic adjustment of the burning proportion, etc. Those Typical features: compact structure, being safe and reliable, being easy to operate,quick installation, little pollution or noise and high efficiency and so on.

The Main Features:

• Three pass structure, large volume combustion chamber, more sufficient burning;
• Advanced wave type furnace structure, increasing the heat transfer area, and realising free expansion;
• Thread structure in smoke tube, improving heat transfer effect;
• Wet-back structure and all pull back edge butt weld, high credibility and low cost of maintenance;
• Back sight device;
• Many protection functions as temperature excursion, overpressure, water shortage, chase leaks, fire extinguishment, etc;
• Beautiful outlook, color grain board, mirror stainless steel and inferior smooth stainless steel;
• Imported burner of good control performance, and full-automation;
• High thermal efficiency, stable output, and strong adaptability to load.
