Pheaton UD 3278k large format printer with 8pcs spt 510 50PL

FOB Price

US$ 5,000 - 13,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Plate Type	Screen Printer
Place of Origin	Guangdong, China	Brand Name	Pheatoon
Model Number	UD-3278K	Usage	Other, Large format advertisment printing
Automatic Grade	Automatic	Voltage	AC110v, 50HZ/60HZ
Gross Power	2200w	Dimensions(LWH)	4950mm1150mm1600mm
Weight	968kg	Certification	CE Cetification
After-sales Service Provided	Engineers available to service machinery overseas

Our Services

1,Big Discount!Best quality and after-service.

2,Welcome to jion our working team ,you will find that we are the same channel !!

We will provide you

1, One year warranty 2, English RIP and Promon printingsoftware
3,Online trainning support 4, Big Discount and patient friendly service

Product Description

Pheaton UD 3278k large format printer with 8pcs spt 510 50PL

High quality printing from Pheaton UD 3278k large format printer with 8pcs spt 510 50PL

Deatails for Pheaton UD 3278k large format printer with 8pcs spt 510 50PL

1, Equipped with 8 PT 510-50PL print heads.

2, AC servo motor is used to run the carriage quicker and more stable.

3, Individual color cleaning minimizes the waste of the ink;

4, 3 way intelligent heater (pre/print/post) helps bring more vivid output

Printhead SII Printek Inc.	SPT510-50PL(Model :UD-3278K)
Number of printhead	8 Heads
Maximum print width	3,200mm
Print Speed (m²/h)	D	2 PASS 157
	S	3 PASS 109
	Q	4 PASS 85
	HQ	4 PASS 70
	C	6 PASS 53
Ink	Type:	Solvent Ink / ECO Solvent Ink
	Color :	Double 4 Color (C,M,Y,K)
	Capacity:	1L or 5L per Main Tank of Each Color
	Ink Supply System	Low Ink Dectector, Auto or Manual Ink Supply System
Media Width	Maximum 3,300mm
edia Type	Vinyl, Window Film, Polyester, Flex, Back-lit Film, etc.
Auto Media Feeding System	Equipped (Max. Media Weight 80kg)
Auto Cleaning System	Individual Positive Pressure Cleaning Anti-clogged Flash Function & Capping System
Pre-heating & Drying System	Equipped
Clamp	Equipped
Print Interface	USB 2.0
Printhead Height	2 to 6 mm from Media
RIP Software	Maintop, Ultraprint, Photoprint, Wasatch, Topaz
Input Power	AC 220V, 50Hz/60Hz
Machine Dimension / N.W	L4, 786 x W1,000 x H1,350mm / 685KG
Package Dimension / G.W	L4, 980 x W1,400 x H1,640mm / 968KG

Packaging & Shipping

Export much container Pheaton UD 3278k large format printer with 8pcs spt 510 50PL to oversea
