Horizontal Three Pass Fire Tube Diesel and Gas Fired Hot Water Boiler
- Qingdao Tianjin or Shanghai
- T/T D/P D/A
You May Like
-
7MW/hr-1.0MPa horizontal auto feed oil fired gas fired hot water boiler with Germany made modulating burner
-
4.2MW/hr-1.0MPa horizontal fully automatic oil fired gas fired hot water boiler with Germany made modulating burner
-
2.8MW/hr-1.0MPa horizontal fully automatic oil-fired gas-fired hot water boiler with Germany made modulating burner
-
1.4MW/hr-1.0MPa horizontal fully automatic oil-fired gas-fired hot water boiler with Italy made modulating burner
-
0.7MW/hr-0.7MPa horizontal fully automatic hot water boiler with Italy made modulating burner
-
Horizontal auto feed hot water boiler with Italy made modulating burner
Product Details
| Condition | New | Type | Natural Circulation | |
| Usage | Industrial | Structure | Fire Tube | |
| Pressure | Low Pressure | Style | Horizontal | |
| Fuel | Gas-fired | Place of Origin | Henan, China | |
| Brand Name | Henan Yongxing, Henan Yongxing Boiler Group Co., Ltd | Model Number | WNS | |
| Output | Hot Water | Dimension(L*W*H) | 6373*2640*3124 (mm) | |
| Weight | 30 Tons | Certification | ISO9001 &ISO14001 | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Horizontal Fully Automatic 4 Ton Diesel And Gas Fired Hot Water Boiler:
WNS series Hot Water Boiler is the kind of automatic, horizontal, ready assembly, internal fired and three-pass fire tube boiler. It adopts the offset furnace and wet-back structure, with high temperature gas traveling the second and the third stoke tube successively and then the smoke is discharged into the air from the smoke room by the chimney. The boiler is equipped with movable forward and backward cover, making the boilers' examination and maintenance convenient and also equipped with a burner of good technological performance, employing those advanced techniques such as the automatic adjustment of the burning proportion, etc.
Main Features:
- Three-pass structure, Fire Tube;
- Stainless Steel Coating---rustproof;
- Imported Diesel Burner from Italy (Brand: Baltur);
- Advanced wave type furnace structure;
- Automatic Feeding System;
- Wet-back structure and all pull back edge butt weld;
- Protection Functions: temperature excursion, overpressure, water shortage, chase leaks, fire extinguishment, etc;
- Beautiful Outlook: color grain board, mirror stainless steel and inferior smooth stainless steel;
- Equipped with Induced Draft Fan, Forced Draft Fan, Automatic Feeding System, and All Safety Devices by law.
The Product Overview
The Parameters of Horizontal Fire Tube Diesel And Gas Fired Hot Water Boiler
| Item | Unit | WNS0.7-0.7/95/70 | WNS1.4-1.0/95/70 | WNS2.8-1.0/95/70 | WNS4.2-1.0/115/70 | WNS7-1.0/115/70 | WNS14-1.25/115/70 |
| Rated Thermal Power | MW | 0.7 | 1.4 | 2.8 | 4.2 | 7.0 | 14.0 |
| Outlet Water Pressure | Mpa | 0.7 | 1.0 | 1.0 | 1.0 | 1.0 | 1.25 |
| Outlet Water Temperature | °c | 95 | 95 | 95 | 115 | 115 | 115 |
| Return Water Temperature | °c | 70 | 70 | 70 | 70 | 70 | 70 |
| Heating Area | m² | 38.97 | 64.964 | 112.48 | 165.99 | 262.79 | 546.5 |
| Thermal Efficiency (oil/gas) | % | 93.08/91.56 | 91.87 | 92.713 | 93.21 | 91.2 | 92.2 |
| Water Volume | m3 | 2.6 | 3.3 | 6 | 9 | 11.6 | 27.6 |
| Design Fuel | Gas/Oil | Gas/Oil | Gas/Oil | Gas/Oil | Gas/Oil | Gas/Oil | |
| Fuel Consumption (oil/gas) | kg,m3/h | 69.16/81.55 | 155.82/155.82 | 253.7/301 | 378.65/449 | 645/765 | 1276/1514 |
| Model (Oil Burner) | L5ZD | TBG210P | BT300DSG | GI420 DSPG | GI1000 DSPG | IBR 8L | |
| Combustion Power (Oil Burner) | KW | 200-850 | 500-1600 | 1034-3854 | 1840-5522 | 2500-10500 | 15630 |
| Motor Power (Oil Burner) | KW | 1.4 | 2.2 | 7.5 | 18.5+2.2 | 22+4 | 45 |
| Model (Gas Burner) | G5/1-D | TBG210P | BGN350LX | GI700DSPGN | TBG1100ME | TS 4G | |
| Combustion Power (Gas Burner) | KW | 170-850 | 400-2100 | 400-3950 | 1300-7000 | 1500-10850 | 3500-17500 |
| Motor Power (Gas Burner) | KW | 1.4 | 3 | 7.5 | 18.5 | 22 | 45 |
| Model (Water Pump) | IVV2.5-12 | IVV2.5-12 | IVV2.5-12 | IVV2.5-12 | JGGC12.5-5*11 | JGGC12.5-5*11 | |
| Head (Water Pump) | m | 120 | 120 | 125 | 125 | 165 | 210 |
| Flow Rate (Water Pump) | m3/h | 2.5 | 2.5 | 6.3 | 6.3 | 12.5 | 25 |
| Motor Power (Water Pump) | KW | 3 | 3 | 5.5 | 5.5 | 11 | 11 |
| Model (circulation pump) | IS80-50-315 | ISG(R)100-65-200A | ISG(R)125-100-250B | ISG(R)125-100-250B | Designed as cilents' requirements | ||
| Head (circulation pump) | m | 32 | 47.6 | 65.3 | 65.3 | ||
| Flow Rate | m3/h | 25 | 56 | 104 | 104 | ||
| Motor Rate | KW | 5.5 | 18.5 | 45 | 45 | ||
Henan Yongxing Boiler Group Co., Ltd, established in 1970s with the registered capital of more than RMB 100 million, is a professional manufacturer and exporter that specializes in the design, development and production of boilers and pressure vessels. All of our products comply strictly with international quality standards and are quite appreciated in a varitey of different markets throughout the world. Our company occupies an area of over 300 acres, with three factories and six subsidiaries.
Our company is bounded by Beijing-Kowloon Railway on the east, and close to 106 country road. Very convenient for transportation!
Factory View
Main Certifications Yongxing Has Gotten
The Cooperation with Foreign Clients
DESCRIPTION HOT WATER BOILER
PRODUCT SIZE 6373*2640*3124 MM
PRODUCT WEIGHT 30 TONS
PORT TIANJIN & QINGDAO
SHIPMENT METHOD FCL & LCL & LOOSE CARGO
40'GP CONTAINER ONE SET
Before the products leave our factories, all the matters relevant to boilers will be undertaken by our company, such as equipment decoration in boiler room and also satisfactory, free-charge service will be offered by us until the turn-key project. The replacement is guaranteed if any problem concerning the product quality arises within a year; Warranty period is ONE YEAR with lifelong service; Our engineers are available at any time of the installation processes if they are needed.
In the manufacturing process, clients are quite welcome to our factory to examine the product quality and to carry out the follow-up inspections.
1. What is our Qualification?
We are a Class A Boiler Manufacturere, with over 30 years' experience in the field of boilers and pressure vessels;
2. What is our main product categories?
We specialize in manufacturing Steam Boiler, Hot Water Boiler, Thermal Oil Boiler, Hot Air Generator (coal/biomass/wood pellet/woodchips, etc, gas/oil/diesel fired), Wood Treatment Plant, Autoclave, Pressure Tanks.
3. What is Our Warranty Period?
One year with lifelong service.
4. How many countries we have exported?
We have exported to FIJI, South Africa, Malaysia, Peru, Chile, Indonesia, Pakistan, Mongolia, Russia, etc.
