DZL10 ton Stainless Steel Milk Can Boiler Industrial Coal Boiler

FOB Price

US$ 8,400 - 840,000 / Set

1 Set(Min. Order)

Port Qingdao/Tianjin/Shanghai
Payment TermsT/T L/C D/P D/A

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Type	Natural Circulation
Usage	Industrial	Structure	Fire Tube
Pressure	Low Pressure	Style	Horizontal
Fuel	Other, biomass fired	Place of Origin	Henan, China
Brand Name	Henan Yongxing Boiler Group	Model Number	DZL2-1.25-AII
Output	Steam	Dimension(LWH)	5.62.53.3M
Weight	18.8T	Certification	ISO9001:2008
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Specifications

1DZL10ton Industrial Coal Boiler
2Compact structure,safe and reliable
3Simple operation,quick installation
4High efficiency

1. Characteristics:

1) Lower fuel consumption.

2) Lower power consumption.

3) Lower heat losses.

4) Boilers are completely trimmed, packaged boilers.

No additional fuel train items or electrical wiring is needed.

5) Integrating with explosion gate, digital control system guarantee the boiler is safe.

6) Horizontal series steam boiler classified atmospheric pressure and pressure endurable structure.

2. Usage:

The steam boiler can be used for producing desired hot water for product manufacturing process in the weave factory, printing and dying, papermaking, and rubber, plastic chemical, pharmaceutical, etc. And for heating room, bath, air conditional, and daily life water in the factories, departments, hotels, schools, restaurants, services industries etc.

Item	Unit	DZL1-1.0-A II	DZL2-1.25-A II	DZL2-2.5-A II	DZL4-1.25-A II	DZL6-1.25-A II	DZL6-1.6-A II	DZL10-1.6-A II	DZL15-1.6-A II	DZL20-1.6-A II
Rated Capacity	t/h	1	2	2	4	6	6	10	15	20
Rated Working Pressure	MPa	1.0	1.25	2.5	1.25	1.25	1.6	1.6	1.6	1.6
Saturated Steam Temperature	°C	183	194	225	193	193	204	204	204	204
Feed Water Temperature	°C	20	20	20	20	20	20	105	105	105
Heat Area	m²	57.47	89.4	94.8	124.9	216.4	227.2	352.2	484	785
Grate Area	m²	2.7	3.54	4.79	5.9	7.54	7.54	13.64	18.8	21.2
Boiler Thermal Efficiency	%	80.42	78.4	78.62	79.7	80.32	80.09	79.8	80.1	81.3
Water Capacity of the Boiler	m³	4.5	3.05	3.76	6.2	10.2	10.2	12.5	14.6	16.7
Exhaust Gas Temperature	°c	120.7	157	165.2	167	125	129.13	167	167	167
Design Fuel		A II	A II	A II	A II	A II	A II	A II	A II	A II
External Dimension(LengthWidthHeight)	mm	527125003154	540024003480	647927563314	617829503350	742030003670	742030003670	860037605500	940038505600	960042005900
