Home > Products > Paintball Machine > S610PB Full Automatic Large Scale Paintball Manufacturing Machine Line
S610PB Full Automatic Large Scale Paintball Manufacturing Machine Line
- Tianjin
- T/T
You May Like
Product Details
| Place of Origin | Beijing, China | Brand Name | Kun You | |
| Model Number | S610PB | Application | Other, Paintball Machine | |
| Type | Other, Paintball Machine | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Paintball Manufacturing Machine Line Description
Configuration
- 1. Encapsulation System
No. | Name | Model | Dimension | Main Material | Spec. | Qty. |
(L*W*H) mm | ||||||
1.1 | Main Machine | S610 | 2050*1200*1850 | SS304&AL | 16kW | 1 set |
Temperature Controlled Hopper | HPR-610 | SS316 | 1 pc | |||
Injection Pump | 0102-10 | 1 pc | ||||
Level Controlled Spreader Box | 0110-215 | Brass | 1 set | |||
Control System | PLC+HMI | 1 set | ||||
Capsule Conveyor | SS belt | SS304 | 1 pc | |||
Micro Ribbon Lubrication System | 1 set | |||||
Independently Driven Capsule Brush | Silicon | 1 set | ||||
Die Roll Complete Set | AL&Brass | 1 set | ||||
Tools, Spare Parts Package | 1 set | |||||
1.2 | Automatic Water Chiller | 2P | 1 set | |||
1.3 | Diaphragm Fill Material Supply Pump | PFS-25 | 1set | |||
1.4 | Capsule Blower | 0.75kW | 1 pc | |||
1.5 | Operation Manual | 1 set |
- 2. Gelatin Preparation System
No. | Name | Model | Dimension | Main Material | Spec. | Qty. |
(L*W*H) mm | ||||||
2.1 | Gelatin Melter | GMT-800 | Φ1400*2750 | SS316 | 7.5kW, 1rpm | 1 set |
2.2 | Control System | SS304 | 1 set | |||
2.3 | Electrical Water Heater | SS304 | 24 kW | 1 set | ||
2.4 | Hot Water In-Line Pump | 150*260*390 | 0.75KW | 1 set | ||
2.5 | Water Sealed Vacuum Pump | 2071 | 442*200*232 | 4kW | 1 set | |
2.6 | Water/Air Separator | Φ300*500 | SS304 | 1 set | ||
2.7 | Gelatin Service Tank | GST-200 | Φ600*1300 | SS304 | 2.5kW | 4 sets |
- 3. Fill Material Preparation System
No. | Name | Model | Dimension | Main Material | Spec. | Qty. |
(L*W*H) mm | ||||||
3.1 | Fill Material Mixer | FMT-500 | Φ1200*2000 | SS316 | 3kW | 1 pc |
3.2 | Fill Material Transfer Pump | 1T | SS | 0.75kW | 1 pc | |
3.3 | Colloid Mill | CM85 | 400*400*850 | SS304 | 4kW | 1 pc |
3.4 | Fill Material Service Tank | MST-1T | 1200*1000*1150 | HDPE | 2.5kW | 1 set |
- 4. Drying System
No. | Name | Model | Dimension | Main Material | Spec. | Qty. |
(L*W*H) mm | ||||||
4.1 | Tumbler Dryer (6 Baskets) | TD-2 | Φ580*900 | SS304 | 4.5KW | 1set |
4.2 | Plastic Tray | DT-750×40 | 750*490*56 | PP | Food Grade | 750 pc |
4.3 | Stainless Steel Trolley | 742*475*130 | SS | 25 pc |
Packing&Shipping
We pack the whole machine with wooden case and pack the softgel die roll and paintball die roll with standard boxes.
We ship the whole line of macine by ocean through the freight agent.
Our services
We not only provide the whole paintball & softgel making machine line, but also can provide the factory design for you. In terms of the after-service, we will be responsible for such services as belows: maintenance, parts supplying, technical support.
Company Information
Beijing KUNYOU Pharmatech Co., Ltd., which is established in 2008, has been focusing on designing, manufacturing and selling pharmaceutical machinery, food machinery and paintball machinery.
KUNYOU Pharmatech provides various models of Softgel Encapsulation Machines (soft capsule encapsulation machine, paintball machine, soft gelatin capsule machine), such as S406 with 6" dies, the medium size S407 with 7.5" dies and the latest and largest S610 with 10"dies. Here, you can find whatever paintballs and soft capsules that you need. Welcome to Beijing KUNYOU Pharmatech Co., Ltd. We look forward to cooperating with you!
Abiding by all efforts for customers’ success and customer first principle, Beijing KUNYOU Pharmatech Co., Ltd. provide top quality products and services. We provide tooling and spare parts for all kinds of softgel main machines. We provide state of the art die rolls for all kinds of softgel machines. We not only offer our clients production equipment and tooling soft capsule, but the complete solution of soft capsule production.
After more than ten years of unremitting efforts, our continuing research and cooperation with many domestic and foreign pharmaceutical factory, plant health products and paintball production factory, not only enable us to make a lot of technical innovation in soft capsule equipment, but also to accumulate rich experience in the production process of soft capsule. After years of great efforts and cooperation with world wide pharmaceutical companies, neutraceutical companies and paintball companies, numerous of improvements were made. We also have rich experience in softgel formulation and manufacturing process. We have three sets of high accuracy CNC milling machine, together with lathe, grinding machine, EDM machine, wire cutting machine, we can make state-of-the-art equipments and softgel die roll.
If you are interested in our products, please feel free to contact us. Welcome!
