2-Speed Duct Exhaust Fan--CE,ERP,SAA,ROHS

FOB Price

US$ 15 - 66 / Piece

50 Pieces(Min. Order)

Port FOB Ningbo
Payment TermsT/T Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Electric Current Type	AC	Blade Material	Plastic
Mounting	Ceiling Fan	Place of Origin	Zhejiang, China
Brand Name	hzzygk or oem	Model Number	HCEU-D
Power	60-380W	Voltage	110-230V
Air Volume	200-1900m³/h	Speed	2450~2650rpm
Certification	CE, ROHS, Other, CE, ROHS, ERP,FCC,SAA,IP4	After-sales Service Provided	Overseas service center available

Product Description

Model 2: HCEU-D [Two Speed Control]

Model	Voltage	Frequency	Power	Rotate	Air Flow	Pressure
(HCEU-D)	(V )	(HZ)	(W)	(R/Min)	(M3/H)	(Pa)
Φ100mm	120 / 230	60 / 50	80	2590	175 / 350	360
Φ125mm	120 / 230	60 / 50	82	2535	215 / 430	350
Φ150mm	120 / 230	60 / 50	120	2350	305 / 610	420
Φ160mm	120 / 230	60 / 50	130	2580	340 / 680	430
Φ200mm	120 / 230	60 / 50	190	2560	550 / 1100	600
Φ250mm	120 / 230	60 / 50	195	2550	600 / 1200	550
Φ305mm	120 / 230	60 / 50	245	2440	925 / 1850	650
Φ315mm	120 / 230	60 / 50	250	2460	950 / 1900	680

1.Typical sizes available: Ø100; Ø125; Ø150; Ø160; Ø200; Ø250; Ø305; Ø315mm

2.Colour available: Black, White, Grey, Green, Yellow, etc

Feature:

1.1 Phase, (Plastic Cased) Powerful and Quiet c/w Mounting Brackets

2.High impact polyester casing complete with detachable mounting brackets and incorporate the reliable

3.Long life, external rotor motor c/w a high efficiency backward curved impellor

4.Low noise and easy to install ideally suited for a wide range of general residestial, commercial and industrial exhaust or supply ventilation applications.
