Qingdao HDPE PE pipe production line for water supply
US$ 30,000 - 80,000
/ Set
1 Set(Min. Order)
- qingdao port
- T/T Credit Card
You May Like
-
Drinking straw production line /Drinking straw extrusion line
-
full automatic drinking straw making machine/drinking straw production line
-
PPR Pipe Production Line/Water Pipe Making Machine
-
CE&ISO Certification PVC Pipe Making Machine/ 100-250mm Water Pipe Extruder Machinery
-
Single-screw Screw Design and New Condition PP PE Drinking Straw /Plastic Drinking Straw Extruder Machinery
-
PE Pipe Production Line With Price / Qingdao Pipe Extruder Machinery
Product Details
| Condition | New | Application | Pipe | |
| Plastic Processed | PE | Screw Design | Single-screw | |
| Automatic Grade | automatic | Place of Origin | Shandong, China | |
| Brand Name | ASUN | Model Number | AS | |
| Voltage | 220/380V | Power(W) | 90KW | |
| Dimension(L*W*H) | 20M | Weight | 5T | |
| Certification | CE | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
HDPE pipe machine for water supply
Introduction
The screw of the extruder equipped with barrier unit and mixing structure, and the barrel owns new style grooves. All of these offer good plastification and mixing effect. Special design of basket die head of for HDPE(PP,ABS) large diameter pipe with thick wall offer lower melting temperature, good mixing, lower pressure of cavity ,and stable production.
Special design for sizing and cooling system by using film and water ring to cool HDPE(PP,ABS)material, which can fit for the requirement of HDPE(PP,ABS).And the design can ensure the stability of diameter and roundness when producing the pipe with thick wall.
Special design vacuum sizing tank can ensure the stability of size and roundness, Speed controllers are used in extruder, haul-off to offer stability and precision.
The whole line adopts PLC control system and large liquid crystal screen, which makes the operation very convenient. The line can be equipped with another extruder used for extruding the mark line.
Detailed Product Description
1.single screw extruder, very suitable to process PE resin with high capacity, max capacity 1000kg/h
2.The production line adopts reasonable design, absorbing safe producing technology, acquiring CE certificate.
3.Diameter range is 16mm-800mm, which can be changed into inch standard to meet clients special requirement.
Technical data
Pipe range | 16-63mm | 20-110mm | 75-160mm | 90-250mm | 110-315mm | 160-450mm | 315-630mm | 500-800mm |
Extruder | ¢45mm | ¢60mm | ¢75mm | ¢75mm | ¢90mm | ¢90mm | ¢120mm | ¢150mm |
Extruder power | AC30kw | DC75kw | DC110kw | DC110kw | DC160kw | DC160kw | DC280kw | DC335kw |
Extrusion capacity | 60-100kg | 100-150kg | 250-300kg | 250-300kg | 350-400kg | 350-400kg | 650-700kg | 850-900kg |
Max. Production speed | 10m/min | 6m/min | 6 m/min | 6 m/min | 3 m/min | 1.2m/min | 0.9m/min | 0.7m/min |
