Home > Products > Bolts&Nuts > Galvanized DIN580 DIN580 Eye Bolt
Galvanized DIN580 DIN580 Eye Bolt
- Qingdao Shanghai or any port in China
- T/T
You May Like
Product Details
| Place of Origin | Shandong, China | Brand Name | Powerful | |
| Model Number | DIN580 | Standard | DIN |
Product Description
Galvanized DIN580 DIN580 Eye Bolt
Eye Bolt
|
|
POWERFUL MACHINERY - EYE BOLT | |
| Description | Large Heavy Duty DIN580 Brass Eye Bolt m4 |
| Place of Origin | Shandong, China(Mainland) |
| Brand Name | Powerful |
| Model Number | Din580 Eye Bolt |
| Material | Alloy Steel, Stainless Steel |
| Surface treatment | Zinc Plated, Electric Galvanized or Hot Dipped Galvanized |
| Color | Self Color or Other |
| Application | Lifting, Rigging |
| Sizes | 6mm to 64mm |
| Accessories | Quick Link, Snap Hook, Hook, G80 Chain, Master Link, DIN582 Eye Nut |
| Packing | All Eye Bolt will be pack in standard seaworthy packing unless instructed by client. Packing: Eye Bolt will be packed in Plastic Bag, Placed in a Cartons and loaded onto a Pallet. |
| Payment | 30% deposit prepaid after confirmed PI. Total balance against copy of BL before cargo arrival. Other Fom of payment can be negotiated as needed. |
| Other Products | 1. NACM Standard Chain 2. Master Link 3. Anchor Chain 4. Shackle 5. Turnbuckle 6. Wire Rope Clip 7. Pulley & Block 8. Load Binder 9. Bolt and Nut 10. Quick Link & Snap Hook 11. Swivel 12. Wire Rope Thimble 13. Carabiner |
| Main market | 1. North America 2. Central America 3. Europe 4. Mid East 5. Southeast Asia |
Powerful Machinery | Product Specification |
Eye Bolt
| |
SIZE (mm) | D2 (mm) | D3 (mm) | B (mm) | Weight Kg/100 PCS | WLL TON |
| 6 | 36 | 20 | 13 | 5 | 0.08 |
| 8 | 36 | 20 | 13 | 6 | 0.14 |
| 10 | 45 | 25 | 17 | 11 | 0.23 |
| 12 | 54 | 30 | 20.5 | 18 | 0.34 |
| 14 | 63 | 35 | 27 | 28 | 0.49 |
| 16 | 63 | 35 | 27 | 28 | 0.7 |
| 18 | 72 | 40 | 30 | 45 | 0.93 |
| 20 | 72 | 40 | 30 | 45 | 1.2 |
| 22 | 81 | 45 | 35 | 67 | 1.5 |
| 24 | 90 | 50 | 36 | 87 | 1.8 |
| 27 | 90 | 50 | 36 | 88 | 2.5 |
| 30 | 108 | 60 | 45 | 166 | 3.6 |
| 33 | 108 | 60 | 45 | 172 | 4.3 |
| 36 | 126 | 70 | 54 | 265 | 5.1 |
| 39 | 126 | 70 | 54 | 280 | 6.1 |
| 42 | 144 | 80 | 63 | 403 | 7 |
| 45 | 144 | 80 | 63 | 425 | 8 |
| 48 | 166 | 90 | 68 | 638 | 8.6 |
| 52 | 166 | 90 | 68 | 660 | 9.9 |
| 56 | 184 | 100 | 78 | 880 | 11.5 |
| 64 | 206 | 110 | 90 | 1240 | 16 |
Powerful Machinery | Product Illustrations |
Eye Bolt 3D Model
Powerful Machinery | Related Product |
DIN582 Eye Nut
320 Crane Hook
Master Link
Powerful Machinery | Packing & Shipping |
All Eye Bolt will be pack in standard seaworthy packing unless instructed by client.
