Home > Products > Special Laser Machines > Four Heads Laser Cutting Machine 1610
Four Heads Laser Cutting Machine 1610
- 200 Set / Sets per Month
- qingdao shanghai ningbo
- T/T Credit Card PayPal
You May Like
Product Details
Laser Type | CO2 | Place of Origin | Shandong, China | |
Brand Name | suke | Model Number | sk1610 |
Product Description
Specifications
Four Heads Laser Cutting Machine1.CE&FDA
2.USB laser cut
3.DSP offline operated
4.LCD panel
Four Heads Laser Cutting Machine
Features:
- Double X axis, Four laser head, more efficient!
- The distance between each laser head can be adjustable,easy to change;Support only one or two laser head working.
- Equipped with imported square linear guide and focusing lens,have higher precison,and the cutting edge is smooth.
- Use high quality reci tube,more stable and durable. With 10000 hours lifespan and 9 month warranty for laser tube.
- Use double three-phase driver and motor for X axis. (Japanese Panosonic servo motor for optional)
Machine:
Technical parameters:
Working area(mm) | 1600*1000mm |
Laser tube power(laser source) | 80w /100w/130w/150w RECI tube |
Laser heads | 4, double X axis |
Working life of tube | 10000 hours |
Engraving speed | 0 - 60000mm/min |
Cutting speed | 0 - 30000mm/min |
Resetting positioning accuracy | 0.01mm |
Laser tuber cooling | Water cooling |
Laser type | Herietic and detached co2 laser tube |
Z axis moving | Automatic |
Max power | Less than 1kw |
Machine control | DSP controlling |
Display Panel | LCD display showing current file name, total working time, laser power, engraving speed, files loaded into memory buffer, setup and diagnostic menus |
Electricity | AC 110 - 220V , 50 - 60Hz |
Min. shaping character | Chinese 2mm*2mm,English 1mm*1mm |
Supported graphic | BMP, HPGL, PLT, DST, DXF, and AI |
Driving system | Stepper motor |
Assistant equipment | Exhaust-fans, water pump air pump. |
Computer interface | Standard printer port and USB port |
Software supported | CorelDraw, AutoCAD , Photo shop |
Additional parts | Rotary attachment |
Red dot | |
Water chiller | |
One set of Lens and mirrors | |
Software | Laser cut |
Operating temperature | 0°C~45°C |
Operating humidity | 5%~95% |
English manual | Tell you how to run the laser machine and also the problems and solutions |
Samples:
Further more information, please feel free to contact with me!!
