PTP Aluminum Foil for Drug Blister Packing

Specifications

PTP Aluminum Foil for Drug Blister Packing

1. Product Structure:

OP 1-2 GSM/ALU 20Mic/VC 2-3 GSM

Thickness: 23Mic~25Mic

 Width: Not more than 1100mm

 Note: Other companys located in China just can Not more than 800mm

2. Description:

(1)Features:
1) Resistant to gas, moisture, light and chemical
2) High stability and sanitation standards
3) one side coated HSL for heat sealing with PVC, PVC/PVDC or ALU ALU FOIL.
4) Applications: Blister packages

(2)Specifications:

1) Alloy: 8011

2) Temper: Hard
3) width: ≤1000mm (according customer requirements)
4) Thickness: 20-30micron (before coating)

5) Classification: Unprinted, printed

6) Coating thickness options:

1. 2-3GSM with tolerance of +/-0.5GSM

3-4GSM with tolerance of +/-0.5GSM

4-5GSM with tolerance of +/-0.5GSM standard, if not specified, heat sealing coating is 3 with tolerance of +/-0.5GSM , both seal strength with PVC/PVDC  7N/25mm min,

2 .primer or OP: 1 GSM

7) Printing and lacquer coating: printed as per text, layout and shade approved by customer. for non-printed specification, clear lacquer to be coated as a protective coating and good printability. Printing inks and lacquer coating are capable to with standard 180deg. C for 1 sec. dwell time. And we could supply aluminum foil for printing on both sides.

8) Structure: HSL/ALU FOIL/ OP

9)Inner packing: Core diameter: 76mm, Out diameter: 240-280mm Max (as your requirement)

10) Out packing: protected by plastic bag, foam, hard carton, wooden pallets.

Use for packing capsule, tablet and so on in alu-alu at the pharmaceutical factory.

3. Composition & Technical Details:

Production process:

Production process:
