Home > Products > New Arrival > Notebook dedicated CPU EM3000DDX22HX E2-3000 - m official version
Notebook dedicated CPU EM3000DDX22HX E2-3000 - m official version
Negotiable
1 (Min. Order)
- D/P D/A
You May Like
-
Original PGA formal version of the core 2 duo T5670 1.8 G 2 m 800 laptop CPU SLAJ5
-
Original Intel Celeron CPU CM370 SL8MM/SL86J CPU original PGA quantities
-
Intel Mobile Core i5-3337u SR0XL BGA1023 original version 2.0 G
-
T7250 2.0 G 2 m, 800, 965 motherboard upgrade T8300 T9300 T9500 notebook CPU motherboard upgrade T8300 T9300 T9500 notebook CPU
-
AMD CPU AMN370DCR22GM N370 laptop 638 needle general N660 N620 P920
-
INTEL notebook CPU T2370 1.73 1 m 533 QWPO QS beta is significant
Product Details
| Products Status | Used | Application | Laptop | |
| Processor Brand | Intel | Type | Dual-Core | |
| L2 Cache | Other | Socket Type | Socket F | |
| Main Frequency | 2.1GHz | Brand Name | AMD | |
| Model Number | A4-3300 | Place of Origin | China |
Product Description
AMD A4-3300M specifications
| General information | |
| Type | CPU / Microprocessor |
| Market segment | Mobile |
| Family | AMD A4-Series for Notebooks |
| Model number ? | A4-3300M |
| CPU part number |
|
| Frequency ? | 1900 MHz |
| Turbo frequency | 2500 MHz |
| Package | 722-pin organic lidless micro Pin Grid Array (UOL722) |
| AMD Package number | 31013 |
| Socket | Socket FS1 |
| Weight | 0.2oz / 6g |
| Introduction date | June 14, 2011 |
| Architecture / Microarchitecture | |
| Microarchitecture | K10 |
| Platform | Sabine |
| Processor core ? | Llano |
| Core stepping ? | LN-B0 |
| CPUID | 300F10 |
| Manufacturing process | 0.032 micron |
| Data width | 64 bit |
| The number of cores | 2 |
| The number of threads | 2 |
| Floating Point Unit | Integrated |
| Level 1 cache size ? | 2 x 64 KB 2-way set associative instruction caches 2 x 64 KB 2-way set associative data caches |
| Level 2 cache size ? | 2 x 1 MB 16-way set associative caches |
| Level 3 cache size | None |
| Multiprocessing | Uniprocessor |
| Features |
|
| Low power features | PowerNow! |
| Integrated peripherals / components | |
| Integrated graphics | GPU Type: Radeon HD 6480G Shader cores: 240 Base frequency (MHz): 444 |
| Memory controller | The number of controllers: 1 Memory channels: 2 Supported memory: DDR3-1333, DDR3L-1333 Maximum memory bandwidth (GB/s): 21.3 |
| Other peripherals |
|
| Electrical / Thermal parameters | |
| V core ? | 0.9125V - 1.4125V |
| Maximum operating temperature ? | 100°C |
| Thermal Design Power ? | 35 Watt |
FAQ
Q: Does this processor support the dual graphics feature?
A: Yes.
Q: Do you have a list of compatible GPUs for dual-graphics?
A: Radeon HD 6430M, HD 6450M, HD 6470M and HD 6490M graphics cards are officially recommended.
Q: I have an AMD A4-3300M microprocessor. Can I upgrade it?
A: Probably yes. CPU compatibility is determined by your motherboard. Please see website for CPU support list for your board.
CPUs, related to AMD A4-3300M
| Model | Cores / Threads | Frequency | Turbo frequency | L2 cache | TDP | Features | |
|---|---|---|---|---|---|---|---|
| AMD A4-Series for Notebooks family, Socket FS1 | |||||||
| A4-3305M | 2 / 2 | 1.9 GHz | 2.5 GHz | 1 MB | 35W | > | |
| A4-3300M | 2 / 2 | 1.9 GHz | 2.5 GHz | 2 MB | 35W | ||
| A4-3310MX | 2 / 2 | 2.1 GHz | 2.5 GHz | 2 MB | 45W | > | |
| A4-3320M | 2 / 2 | 2 GHz | 2.6 GHz | 2 MB | 35W | > | |
| A4-3330MX (L2 1MB) | 2 / 2 | 2.3 GHz | 2.6 GHz | 1 MB | 45W | > | |
| A4-3330MX | 2 / 2 | 2.2 GHz | 2.6 GHz | 2 MB | 45W | > | |
| Other families, K10 micro-architecture, Socket FS1 | |||||||
| E2-3000M (HX) | 2 / 2 | 1.8 GHz | 2.4 GHz | 1 MB | 35W | > | |
| E2-3000M | 2 / 2 | 1.8 GHz | 2.4 GHz | 1 MB | 35W | > | |
| A6-3400M | 4 / 4 | 1.4 GHz | 2.3 GHz | 4 MB | 35W | > | |
| A6-3410MX | 4 / 4 | 1.6 GHz | 2.3 GHz | 4 MB | 45W | > | |
| A6-3420M | 4 / 4 | 1.5 GHz | 2.4 GHz | 4 MB | 35W | > | |
| A6-3430MX | 4 / 4 | 1.7 GHz | 2.4 GHz | 4 MB | 45W | > | |
| A8-3520M | 4 / 4 | 1.6 GHz | 2.5 GHz | 4 MB | 35W | > | |
| A8-3510MX | 4 / 4 | 1.8 GHz | 2.5 GHz | 4 MB | 45W | > | |
| A8-3530MX | 4 / 4 | 1.9 GHz | 2.6 GHz | 4 MB | 45W | > | |
| A8-3550MX | 4 / 4 | 2 GHz | 2.7 GHz | 4 MB | 45W | > | |
