pet bottle linear stretch blow molding machine SFL4
- NINGBO/SHANGHAI
- T/T
You May Like
-
2L water bottle rotary blow molding machine
-
4cavities Bottle Servo Energy Saving Automatic Plastic Blow Molding Machine
-
DMK-L4 Full Automatical Liner PET Bottle Blow Moulding Machine
-
PET Injection Mold Blow Moulding Machine
-
Rotary Blow Molding Machine injection preform
-
PET Bottle Linear Blow Moulding Preform Injection Machine
Product Details
| Condition | New | Application | Bottle | |
| Plastic Processed | PET | Blow Moulding Type | Stretch Blow Moulding | |
| Automatic | Yes | Place of Origin | Zhejiang, China | |
| Brand Name | DEMARK | Model Number | SFL4 | |
| Voltage | Customer | Power(W) | 40-60 | |
| Dimension(L*W*H) | 4.9*2.4*2.6 | Weight | 6000kg | |
| Certification | ISO9001:2008 | Warranty | 1 Year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
PET BOTTLE LINEAR STRETCH BLOW MOLDING MACHINE SFL4
This is our new style- high speed blow molding machine , it's main advantage is high production, lower energy consumption and quality bottle.
Main technical:
Type |
| Unit | SFL4 |
Productive output | Base on 500ml | Bottle/hour | 5200 |
Forming Specification | Mould plate stroke | mm | 150 |
Stretching stroke | mm | 330 | |
Bottom die trip | mm | 30-50 | |
Cavity | pcs | 4 | |
Cavity spacing | mm | 127 | |
Bottle specification | ntainer volume | L | 2 |
Max.neck diameter | mm | 30 | |
ntainer diameter | mm | 105 | |
ntainer height | mm | 330 | |
Max.perform height | mm | 150 | |
Electrical specification | Heating boxes number | pcs | 4 |
Heating lamps | pcs | 10 | |
Maximum heating power | KW | 102 | |
Installed the total power | KW | 125 | |
Actual power consumption | KW | 40-60 | |
Electrical voltage / Frequency | V | 380(50Hz) | |
Air pressure specification | Operataiting pressure | Kg/cm2 | 7 |
Low pressure consuming | L/min | 2000 | |
Blowing pressure | Kg/cm2 | 35 | |
High pressure consuming | L/min | 6000 | |
Chiller water specification | Cold water machine pressure | Kg/cm2 | 2-4 |
Temperature range | ℃ | 10 | |
Consumption | Kcal/hr | 45000 | |
Machine specification | Machine dimension | m | 4.9*2.4*2.6 |
Machine weight | T | 6 |
Company workshop:
we have three branches. One is taizhou workshop for mold, one is wuzhou workshop for blow molding machine and injection machine. Shanghai office is our sales office.
