Home > Products > Solar inverter > 1000W Modified Sine Wave Inverter

1000W Modified Sine Wave Inverter

FOB Price

US$ 71 - 82 / Piece

250 Pieces(Min. Order)

Port SHANGHAI / NINGBO
Payment TermsT/T L/C D/P D/A Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Zhejiang, China	Brand Name	HOLLEY
Model Number	HIMB1000	Output Power	Other, 2000W
Output Type	Single	Size	32.5 x 20.8 x 7.7 cm (L x W x H)
Weight	2.5 KG	Input Voltage	12/24/48Vdc
Output Voltage	110/240Vac	Type	DC/AC Inverters
Output Frequency	50/60HZ	Output Current	-

Product Description

1000W modified sine wave inverter.

Products Features:
1. High Surge: high surge current capability starts difficult loads such as TVs,camps,motors and other inductive loads,
2. Earth Fault Protection: The unit shutdown when the load has electric leakage.
3. Soft start : smooth start-up of the appliances.
4. Pure sine wave output waveform : clean power for sensitive loads.
5. AC output identical to, and in some cases better than the power supplied by your utility
6. Cooling fan in the inverter is thermally activated and comes on when the inverter becomes warm,and turns off automatically after the inverter has cooled.
7. Low total harmonic distortion : below 3%
8. Two LED indicators on the front panel shows the working and failure state.

Detailed Images

Technical data

Model	HIMB1000-121	HIMB1000-122	HIMB1000-241	HIMB1000-242	HIMB1000-481	HIMB1000-482
Rated Power	1000W
Surge Power	2000W(Few seconds)
Input Voltage (DC)	12V	12V	24V	24V	48V	48V
Output Voltage (AC)	100-127V	220-240V	100-127V	220-240V	100-127V	220-240V
Frequency	50/60±0.5Hz
Output Waveform	Modified Sine Wave
No Load Current Draw	≤0.8A
USB Output	5V500mA(Optional)
Protection Function	Low voltage alarm & shut down, Over temperature, Over voltage, Overload, Short circuit, Reverse polarity, Earth leakage.
Low Voltage Alarm	10.5±0.5V	10.5±0.5V	21±0.5V	21±0.5V	42±1V	42±1V
Low Voltage Shut Down	10±0.5V	10±0.5V	20±0.5V	20±0.5V	40±1V	40±1V
Low Voltage Recovery	13±0.5V	13±0.5V	24±0.5V	24±0.5V	48±1V	48±1V
Over Voltage Shut Down	15.5±0.5V	15.5±0.5V	31±0.5V	31±0.5V	61±1V	61±1V
Over Voltage Recovery	14.8±0.5V	14.8±0.5V	29.5±0.5V	29.5±0.5V	59±1V	59±1V
Dimension	32.5 x 20.8 x 7.7 cm (L x W x H)
Net Weight/Unit	2.5 KG
Package Information	50 x 33 x 44.5 cm (6 pcs/ctn)
Certificate	CE

Packing & Delivery

Certifications

500W Modified solar inverter.

Rated power: 500W

Surge Power: 1000W

800W Modified solar inverter.

Rated power: 800W
Surge Power: 1600W

1500W Modified solar inverter.

Rated power: 1500W
Surge Power: 3000W

Our Company

HOLLEYINTL, is a top-brand enterprise in China, is a professional diversified operating company specializing in international trade and overseas projects. We have been engaged in export and import of utility meters, new energy and natural resource products as well as overseas engineering EPC and investment. Meanwhile, our company is also the inverter,controller manufacturer; PV system integrator and photovoltaic power plant investment operator.

We actively carrying out the internationalization strategy and extending the domestic and overseas markets, have made great progress in the field of new energy and completed a number of photovoltaic system projects in Ethiopia, Uganda, Palestine as well as other countries, and initially formed the core competence both in PV system integration capabilities and customer service network.

As one of our global strategies, we are aiming to be an global excellent integrated expert in new energy field. We specialize in providing design, supply, installation, commissioning, after-sales service and project finance support of overseas new energy projects and our products have been spread all over Africa, Asia and South America.
