Home > Products > Sand Blast Hose > Wear Resistant ID51mm Sand Blast Hose
Wear Resistant ID51mm Sand Blast Hose
- Tianjing China
- T/T
You May Like
Product Details
| Place of Origin | Hebei, China | Brand Name | HUAYU | |
| Model Number | Sand Blast Hose |
Product Description
Sand blast Hose
Specifications
1. flexible rubber sand blast hose
2. steel wire braided or fabric and cord
3. Hose coupling available
4. manufacture
The Sand Blast Hose is used for conducting sand, steel, shot or other abrasives at high velocity, often in conjunction with blasting, cleaning or finishing stone, metal, and other surfaces.Construction consists of thick plies of an abrasion resistant, static-conducting tube, with a black abrasion resistant cover. Used with OD mounted sand blast couplings.
Temperature range is -25F to 180F.
| hose lining | The outer rubber
| |
Tensile Strength Mpa% ≥ | 15.0 | 13.0 | |
derrick wagon crane Mpa% ≥ | 530 | 320 | |
Test conditions for hot air70℃×72H | Variation of tensile strength % | ±25 | |
Elongation at break % | +10 -30 | ||
The wear volume (cm3) ≥ | 0.35 | ||
The adhesion strength between the layers ≥ | 2.0 | ||
ID (mm) | ID (inch) | OD (mm) | PLIES | Working pressure | |
(psi) | (bar) | ||||
13 | 1/2 | 1*1/32 | 2 | 150 | 10 |
19 | 3/4 | 1*3/8 | 2 | 150 | 10 |
25 | 1 | 1*9/16 | 2 | 150 | 10 |
32 | 1-1/4 | 1*27/32 | 2 | 150 | 10 |
38 | 1-1/2 | 2*1/8 | 2 | 150 | 10 |
51 | 2 | 2*11/16 | 2 | 150 | 10 |
Mainly produces:
1. Resistance burning antistatic high pressure steel wire spiral rubber hose, high pressure braided hose, high temperature resistant rubber hose,CONCRETE PUMP HOSE.
2. Super high pressure steel wire hose and high pressure hose assembly.
3. Drilling hose,Floating Dredging Hose,Marine oil hose large caliber,Dredger Hose,Flame resistant hose,Dredger Suction and Discharge Hose.
4. Oil field special rubber seals.
5. Solid control parts: Hammer Union, Air Grip Unions, mud tank unions.
6. Air Operated Thread Protectors,Mech-Tec (TM)Clamp-On Thread Protectors.
The company since its inception, relying on science and technology for development. Established long-term cooperative relations with chemical shenyang rubber research institute, has the research, development, production of hundreds of special rubber products, in the domestic each big oil fields, steel mills, mining, machinery and other industries has been the user's consistent high praise, and exported to South Korea, Mongolia, Russia and other countries.
Any needs for API 7K Drilling hose, Concrete hose, High pressure hose, hydraulic hose and Hammer Union, just contact me!
