Low Cost Light Structural Steel Frame For Storehouse

Bellow materials are general used in steel buildings , but we often customized each type depend on clients requirment .

Poultry House Whole View

   Inside photos automatic feeding and drinking system:

The function of deliver system is to transmit the feed outside shed to the hopper of feeding system inside; control system indicates delivery system to work automatically.

Feed of poultry raising farm is stored in the silo, so as to save large amount of package, and also to ensure the health of feed. Different specifications of silos are alternative to choose according to the daily consumption and the size of silo. Material of silo consists of galvanized sheet and glass fiber reinforced plastic.About this project, 20000 broiler chickens, we can choose 5.4t

 Feeding Line

   Feed pan is the core of feeding system. Feed in the hopper is delivered by the motor, through delivery pipe to fulfill feed pans one by one. When all of the feed pans are all of feed, control box will stop the motor from working.

The length of one feed line will not longer than 150m, so the length of chicken house can’t be longer than 150m. This is the important thing to concern when design the size of the chicken house.

The distance between 2 feeding line is about 4m. This is also the important thing to concern when design the size of chicken house.

 Cooling Pad System

   Evaporative cooling pad system works in the condition of negative pressure, the cooling pad is installed on one side of the wall, fan installed other side. Air flow through cooling pads, the water evaporation absorbs a lot amount of heat.

The height of cooling pad is 1.5-2.2m; length about 3m, the area of cooling pad in chicken house is about 6-8 times than the fans.

 Ventilating System

   The main parts of ventilation system are the big fan and small fan. They are controlled by the control system. The number of the fans to run was decided by the temperature of the poultry house.

About 200m² needs 1 big fan and 15-20m² need a small fan, this is the standard to design the quantity of fans in chicken house.

 We have two heavy steel production lines and four light steel production line

       Qingdao Baorun Steel structure Engineering Co.,Ltd. was eatablished in 2000,and the registered capital of the company is 51.18 million Yuan. Now the company has 5 pressure-type color steel plate production lines,2 heavy steel production lines,1 H-beam CNC secondary processing production line (3D CNC drilling machine,CNC sawing,CNC milling machines,etc.), and 2 Hbeam shot blasting machines, one 4 m wide flat-biasting machine,4 CNC cutting machine sets,8 automatic submerged arc welding machine,1 CNC plant drilling machine and 2 CNC Bending Machine (macimum thickness og 50 mm),2single-arm welder (10m),etc.The annual output of the company is 40000 tons of light steel,50000 tons og heavy steel,with 3million square meters of color plates and completion of the light steel plant 500000 square meters per year.Qingdao Jinmaoyuan Steel Structure Engineering Co.,Ltd.is located in the beautiful scenery of Qingdao Economic and Technological Development Zone, and it covers an area of 70000 square meters ,the construction area is 50000 square meters .

    The company has achieved a successful transiton to the production of marine steel platform in 2007!Now the company has become the qualified subcontasctors of Offshore Oil Engineering (Qingdao) Co,Ltd.China National Petroleum Offshore Engineering Co.,Ltd.,Qingdao,Wuhan Shipbuliding Industry Co.,Ltd, and other famous enterprises!
    The company has passed the ISO9001 international quality system certification, ISO14001 environmental quality system certification,GB/T28001 Occupation Health and Safety Management System Certification in the industry og construction and installation of steel in Qingdao
Our products is about civil construction,heavy steel structure,stadium,industrial workshop , warehouse building steel structure ,villa ,container house, hanger ,garage,poulty house prefabricated house, with good quality and pretty competitive price.

Our company

 Our machine

 our finished product

our  Certificate

      Only provide us with the following information, you can get a quotation:

            1. Size: Length* Width*Height (eave height)
            2. Local wind speed(km/h),Snow load(kg/m2)
            3. Wall and Roof: Steel Sheet or Sandwich Panels?
            4. Door and Windows: Size and Quantity
            5. Other needs or not: Gutter, Down Pipe, Skylight Panels, Fan
            6. Crane: if have, pls tell me the crane span, crane lift height, max lift capacity
            7. As your drawings or requirements..

               1. Q: Are you the factory or the trading company?
                A: Certainly. We are the factory, we can give you the best price.
            2. Q: Do you have the experience to cooperate with the government ?
                A: Well. We have much experience to cooperate with the government , also we love to do it. We have cooperated with Maldives Government, India Government, Indonesia Government, East Timor Government, Philippines Government, Pakistan Government and so on.
            3. Q: How is your after-sales service?
                A: 1.Any question, welcome to contact us.24 hours available for you.
                     2. One order, one special person to follow the whole production.
                     3. For the house install, we will give you the 3D install drawing. If you need, we also can send you an engineer to teach your workers, but you have to charge the double ticket, accommodation, food and salary.
           4. Q: What information should we offer before you quote?
               A: If you have the drawing, pls give us and tell us the material you use.
If no drawing, pls tell us the usage and the size of the house, then we design for you with the good price.

            I will give you quotation as soon as possible.If some question on the quotation progress,I will contact with you anytime.
           Best regards and wish you a nice day!
