Automatic Puffed/fried Snacks Food Process Line

Specifications

Double Screw Extruder can use corn flour, wheat flour, rice flour, soya bean meal, peanut meal etc to produce inflated snacks and non-inflated pellets products by changing screws.

It consists of feeding system, extruding system, cutting system, heating system, driving system, lubricating system, water-cooling system and controlling system.

1. The screw is made of alloy (38CrMoAL) by nitriding process, high strength and wear-resting. And it has good self-cleaning ability and does not need to discharge or clean the barrel and screw, when roasting or replacing of materials.

2. It adopts speed-adjusted converter on feeding system, extrusion system and cutting system. Food grade stainless steel twin screw feeding machine guarantees stable materials feeding in the whole food process.

3.The gearbox has automatic lubrication function, with extends gear life.

4. Radiator is increased on driving part for forced cooling effect, and it ensures extruder operate safely.

5. Barrel with water-cooled circulation, it makes extruder can be used not only for corn/rice, also for wheat flour/starch which are raw materials with high viscosity. Through different moisture-extrusion temperature ratio, it can make whole-expanded and half expanded as different type of products.

6. Cutting knife fixed in the die head seat, rotary cutting by V-belt drive.

Fumigation-Free Wooden Cases

1, Supply all information about the machinery to seller if customer require, such as the price list, the operation instruction, the video or other.

2, we will prepare and send all documents before goods reaching destination port. The documents include sales contract, commercial invoice, Packing list and other certificate.

3, If customer can not install and operate the machine, we will show clients the install instruction or video. If customer still can not do it, we will send our engineer to install and teach them to use.

4, One year warranty. Within one year from the signed contract, we can provide free service.

Zhucheng Xinxudong Machinery Co.,Ltd. has established for nearly 15 years, expertise in food machines manufacturing. As a factory, we have 7 machinery variety and more than 100 kinds of food product processing machinery. With reliable quality and hearty services, we have exported to Australia, Russia, Poland,Lebanon, Uzbekistan, Morocco, India, Bangladesh, Iran, Libya, U.A.E., Saudi Arabia, Syria, Iraq, Vietnam,Japan,Malaysia, Burma,Pakistan, Indonesia, Mongolia, Egypt, Algeria, Ethiopia, Tunisia, Brazil, Venezuela, etc.
We are one of the earliest and manufacturer in China to make food machines.

The main products are following:

1.Potato chips / french Fries processing line

2.Forming and coating processing line

3.Puffing food processing line

4.Snack food processing line

5.Beans and nuts processing line

6.Fish balls and meat balls processing line

7.Vegetable and fruit processing line
