High Quality 96% Alumina Ceramic Substrate//Industrial Insulating Plate
- Chengdu Air Port/Shanghai Sea Port
- T/T Money Gram Credit Card
You May Like
Product Details
| Place of Origin | Sichuan, China | Brand Name | JIABANG | |
| Model Number | Customized | Type | Insulating Ceramics | |
| Material | Alumina |
Product Description
High Quality 96% Alumina Ceramic Substrate/Industrial insulating Plate
1.Superior reliability and durability
2.Support Laser cutting, Mould, injection production technologies
3.The ceramic plates can be made according to the customers' requirements
4.Good chemical capability and hight insulation,Good Bending strength
Applications
96%Al2O3 ceramic substrates are widely used in many applications,including HIC,chip Resistance,network resistance,Focalized potentiometers,Semiconductor Congealers and power Modules.
PROPERTY
| TESTING CONDITIONS | UNITS | VALUE |
Color |
|
| White |
Appearance |
|
| Compate |
Density |
| g/cm3 | 3.7 |
Water Absorption |
| % | 0 |
Medium grain size |
| μm | 3~5 |
Hardness | Loaded 4.9N | GPa | ≥15 |
Bending Strength |
| MPa | ≥274 |
Coefficient of liner Expansion | 20~500°C | 1×10-6mm/°C | 6.5~7.5 |
| 20~800°C |
| 6.5~8.0 |
Thermal Conductivity | 20°C | W/(m·K) | ≥20.9 |
Specific Heat |
| kJ/(kg·K) | ≥0.8 |
Dielectric Strength |
| KV/mm | ≥12 |
Volume Resistivity | 20°C |
Ω·cm | ≥1014 |
| 300°C |
| ≥1011 |
| 500°C |
| ≥109 |
Dielectric Constant | 1MHz |
| 9~10 |
tangent of Dielectric loss | 1MHz |
| ≤3×10-4 |
Surface roughness |
| μm | 0.3~0.8 |
ing temperature |
|
| 1600 °C |
Please let us know the 5 important things of your need for product.
1. What size of product do you need?
2. What about is the allowable tolerance?
3. what is the material do you need for the ceramic product?
4. where do you use such substrate ?
5. How much is your quantity demand?
#If you can give us your technic drawing,we will be very appreciate.
If you need more information or have any question,pls kindly let us know and we will reply to you A.S.A.P!
