Home > Products > CNC PRESS BRAKE > WC67Y-250/6000 Heavy Duty Cnc Press Brake From ShenChong Brand With Competitive

WC67Y-250/6000 Heavy Duty Cnc Press Brake From ShenChong Brand With Competitive

FOB Price

US$ 45,000 - 52,000 / Set

1 Set(Min. Order)

Port SHANGHAI
Payment TermsT/T D/P D/A Money Gram

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Jiangsu, China
Brand Name	shenchong	Model Number	WC67Y- 250/6000
Machine Type	Press Brake	Raw Material	Sheet / Plate Rolling
Material / Metal Processed	Carbon Steel	Power	Hydraulic
Automation	Automatic	Extra Services	End Forming
Certification	CE	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Feature:

1. THE WHOLE STRUCTURE OF THE MACHINE
Welded steel plate, the frame consists of right and left wall boards, working table, oil box, groove steel and etc. The stress of the parts has been eliminated by vibration. The machine enjoys high accuracy and high strength and good rigidity.
2. HYDRAULIC SYSTEM
All the hydraulic sealing parts are up to the state standard and have excellent quality to avoid leakage. Pump oil filters and motors are products of famous producers inland. All of them are advanced performances and reliable quality. All hydraulic parts have passed strict inspection and test to eliminate hidden trouble before usage.
3. SYNCHRO CONTROL SYSTEM
The slide synchro system adopts steel torsion bar synchro system with very simple structure but very high accuracy. 2 ends of slide has 2 synchro fork which make the slides movement is always parallel to the working table. And this will make the movement effect balanced during operation.

Technical parameter as follows:

1	Type	Hydraulic press brake
2	Nominal power (KN)	2500KN
3	Length of working table	6000mm
4	Internal space of upright posts	4500mm
5	Depth of throat	400mm
6	Slider stroke	240mm
7	Max opening height	525mm
8	Main motor	15KW
9	Control system	Estun E10
10	G.W.	24000kgs
11	Before packing size(mm)	6100X1890X3350

CE certificate:

Factory:
