famous brand Aluminum composite panel in Guangdong PVDF coated Interior design
- Shen Zhen/Shan Tou
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | Yuntai | |
| Model Number | YT154 | Usage | Outdoor | |
| Function | Anti-Static, Antibacterial, Fireproof, Mould-Proof | Surface Treatment | Anodized, Brushed, Foil Decoration, Mirror, PE Coated, Printing, PVDF Coated, Other, Anodized, Brushed, Foil Decoration, Mirror, PE Coated, Printing, PVDF Coated, FEVE |
Product Description
PHYSICAL PROPERTIES
| Properties | 2 mm | 3 mm | 4 mm | 6 mm |
| Aluminum thickness, in (mm) | 0.010 (0.25) | 0.010 (0.25) | 0.020 (0.5) | 0.020 (0.5) |
| Weight, psf (kg/m2) | 0.59 (2.9) | 0.80 (3.9) | 1.12 (5.5) | 1.50 (7.32) |
| Coefficient of expansion, ASTM D696, in/in/°F | 13 × 10^-6 | 13 × 10^-6 | 13 × 10^-6 | 13 × 10^-6 |
| Tensile strength, ASTM E8, psi (MPa) | - | - | 6913 (48) | 4978 (35) |
| Yield strength, ASTM E8, psi (MPa) | - | - | 6429 (44) | 4466 (30) |
| Elongation | - | - | 13.50% | 17.50% |
| Thermal conductance, ASTM C976, Btu/(ft2 × h × °F) (W/(m2 × K)) | - | - | 10.75 (18) | 8.53 (14) |
| Minimum Drum peel, ASTM D1781, in-lb/in(N-mm/mm) | - | - | 22.5 (100) | 22.5 (100) |
| Thermal resistance, ft2 × h × °F/Btu (m2 × K/W) | - | - | 0.09 (0.016) | 0.12 (0.021) |
| Sound transmission coefficient, ASTM E413 | - | - | 26 | 26 |
FIRE PERFORMANCE PROPERTIES
| Properties | 4 mm | 6 mm | ||
| Surface burning characteristics, ASTM E84 | ||||
| Smoke developed index | 450 maximum | 450 maximum | ||
| Flamespread index | 25 maximum | 25 maximum | ||
| Vertical transmission, ASTM E108 (modified) | Passed | Passed | ||
| Ignition temperature, ASTM D1929 | ||||
| Flash ignition | 716° F (380° C) | - | ||
| Self-ignition | 752° F (400° C) | - | ||
| Rate of burning, ASTM D635 | CCI | - | ||
Our prodcuts have been applied to different kinds of decorations all over the world. Exterior decoration,interior decoration,signs,airports,etc. Take the airport here in JieYang for example, every single piece of Aluminium Composite Panel(ACP Panel) you can see there was all made in our factory!
We have all the usual colors for this item ( Panel Sandwich Plastic Stone Wall Panels Alucobond Prices ). Colors remain bright and vivid after long time duration even under server weathering condition. You can also send us samples or provide Ral or/and Pantone color numbers so we can make exact colors that meet your need.
Below is general packing information for one 20'GP
1. Approximately 2,300 sheets(1220*2440*2.7MM) without package;
2. Approximately 2,100 sheets(1220*2440*3.0MM) without package;
3. Approximately 1,600 sheets(1220*2440*4.0MM) without package.
If you need wooden case packing or other specification of ACP,kindly let us know. We will provide detailed information so you can have an idea of loaded quantity and shipping cost.
