Wifi IP Camera C7816WIP Wireless 720P Security Camera outdoor cctv camera

Model :C7816WIP

Features

System security

8-level user authority management, built in watchdog,can auto test chipset and software.

Built-in dynamic IP

 domain system (Free)

 No need domain name, support dynamic IP.

Mobileview platform

 No need install software, multi-channel mobile view, support mobile view alarm snapshot.

Plug & Play

Plug & Play technology applied.99% penetration rate.

Only three steps to view image.

UID Technology

Unique scan UID to add camera, easy to operate, and highly confidential.

CMS

1,4,9,16,25,36,64,81-channel central management surveillance system, no user limitation.

 Centralized monitoring, remote recording, remote playback.

Core

O.S

Built in Linux

Control protocol

ONVIF protocol,high interoperability

Processor

 Hi3518C processor,built in ARM9 @Max. 440MHz and High-speed

video co-processor

Video

Compression format

H.264 Baseline Profile @ H.264 Main Profile@MJPEG/JPEG Baseline

resolution/frame rate

720p/VGA/QVGA   30fps/25fps

Image adjustment

Brightness, Contrast, Saturation are adjustable

Sensor

1/4 720p Progressive CMOS sensor

Minimum illumination

1.0 Lux / F1.2

CMOS

support AWB,AGC,BLC

Sensor size

3.84mm×2.16mm

Video coding

Multi stream 720P@30fps+VGA@30fps+QVGA@30fps+720P @1fsJPEG capture

Bit Rate

CBR/VBR,output range:32kbps~40Mbps

 Lens/viewing angle

3.6mm  @  F1.4/35.49  degree

Night Vision

Night vision

Dual IR-CUT Filter auto switch, 2pcs 2pcs 850nmΦ28Mil LED,15m IR distance

Network

Socket

10/100Mb   self-adaptable Ethernet slot

Network Protocol

TCP/IP,HTTP,RTSP,TCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,

UPnP,PPPOE,P2P ect.

Online visitor

Support 10 online visitors viewing simutaneously

IP address

Dynamic IP and static IP address

Network adaptability

 can auto adjust stream and frame rate according to the bandwidth

Others

Housing material

Engineering-plastics

Use Enviroment

both indoor and outdoor

Power supply

DC12V±10%

Working temperature

 -20 ~ 50 °C

RTP

Support RTP, can auto adjust time when restart after power failure.

Accessories

Power adapter, user manual, warranty card,mounting bracket,screws.

Alarm

Input/Output

Input 1, Output1

Motioin Detection

can setup motion detection sensitivity

Alarm notification

E-mail snapshot, FTP upload alarm pic and video.

System

 Requirements

Operating System

Win98 SE/ME/2000/XP/Vista/win7  IE5.0, NET4.5, firefox, chrome

Certificate

Certificates

ISO FCC CE RoHS
