output 12v 0.1-0.833a constant voltage 10w led driver size 90*30*20mm
- shenzhen
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
700mA DC 9-15V dimming led driver size 80*42*24MM
-
15V-35V 320mA DC dimming led driver 80*42*24MM
-
12v 100w constant voltage waterproof square led driver circuit
-
12v 5a 60w waterproof IP67 square led driver power supply
-
12V 2A 24w ac dc waterproof IP67 switching mode power supply for LED driver
-
100w metal cases driver for LED strip
Product Details
| Place of Origin | Guangdong, China | Brand Name | FEKKO | |
| Model Number | SAW120833CV | Usage | Other, LED equipment, light etc., Switching | |
| Output Type | Other, DC, DC | Connection | Other, Desktop, Desktop |
Product Description
10W DC 12V Constant Voltage LED Driver
Voltage Range: 90~264VAc
Frequency Range: 47~63Hz
Efficency: >85%
AC current (max): 0.7A @ 220V, 2.0A @ 115V
AC Inrush Current: 40A @ 230V
DC Voltage: 12V
Rated Current: 0.1-0.833A
Ripple & Noise (max): mVp-p < 1% Uout
Load Regulation: +/- 1%
Setup Time: 500ms
Rise Time: 20ms
Hold UP Time: 30ms @ 230V, 10ms @ 115V
Short Circuit Protection
Overload Protection: 130~150%
Over Voltage Protection: 115~135%
Thermal shutdown
Working Temperature: -20~50℃
Working Humidity: 20%~90% RH
Storage Temperature: -40~60 ℃
Storage Humidity: 20%~95% RH
Safety Standard: meet CE, FCC, GB,CCC, ROHS
Withstand Voltage: IP/OP 5mA 2KVAc
Isolation Resistance: IP/OP 100M Ohms
Waterproof Rank: > IP67
Dimension: 90*30*20mm
A PROFESSIONAL ADAPTER and POWER SUPPLY MANUFACTURER in Shenzhen over 10 years
Our factory':
5,000 square meters
150 well-trained staff
18 R&D engineers
18 QC auditors
4 SMD workshops, imported equipment from Japan
2 semi-automated production lines
500K/M current monthly capacity
ISO9002 quality assurance
UL/CUL , CE, FCC, CCC, KC, GS, TUV , C-TICK , SAA,CB, ROHS approvals , 6 level efficiency .
