Product Details
| Place of Origin | Shaanxi, China | Brand Name | XH | |
| Model Number | W50Cu50,W60Cu40,W70Cu30...etc | Dimensions | customized |
Product Description
Super Quality Tungsten cooper plate, rod,ring,wire,tube
Specifications:
GRADE | CHEMICAL CONTENT | DENSITY | HARDNESS |
|
|
| ||
Cu | IMPURITY ≤ | W | g/cm3 ≥ | HB Kgf/mm2 ≥ | μΩ.cm ≤ | % ≥ | MPa ≥ | |
W50/Cu50 | 50±2.0 | 0.5 | BAL | 11.85 | 115 | 3.2 | 54 | -- |
W55/Cu45 | 45±2.0 | 0.5 | BAL | 12.3 | 125 | 3.5 | 49 | -- |
W60/Cu40 | 40±2.0 | 0.5 | BAL | 12.75 | 140 | 3.7 | 47 | -- |
W65/Cu35 | 35±2.0 | 0.5 | BAL | 13.3 | 155 | 3.9 | 44 | -- |
W70/Cu30 | 30±2.0 | 0.5 | BAL | 13.8 | 175 | 4.1 | 42 | 790 |
W75/Cu25 | 25±2.0 | 0.5 | BAL | 14.5 | 195 | 4.5 | 38 | 885 |
W80/Cu20 | 20±2.0 | 0.5 | BAL | 15.15 | 220 | 5 | 34 | 980 |
W85/Cu15 | 15±2.0 | 0.5 | BAL | 15.9 | 240 | 5.7 | 30 | 1080 |
W90/Cu10 | 10±2.0 | 0.5 | BAL | 16.75 | 260 | 6.5 | 27 | 1160
|
types,chemical compositions and main properties of tungsten cooper alloy plate:
Type | chemical composition of copper tungsten alloy(%) | resistivity(cm) | tensile strength(kg/mm2) | hardness | density(g/cm3) | |
W | Cu | |||||
F6002E | 60 | balance | <=3.26*10-6 | >=130 | >=160 | >=12.70 |
70 | <=3.80*10-6 |
| >=200 | >=13.80 | ||
80 | <=4.00*10-6 |
| >=220 | >=15.00 | ||
Application of tungsten copper:
Tungsten copper Alloy (W-Cu alloy) is the composite of tungsten and copper which own it excellent performance of tungsten and copper. It is used widely in such industries as engine, electric power, electron, metallurgy, spaceflight and aviation.
a. High Performance Material for Aerospace Industry
b. Vacuum contact materials
c. Electrodes for electrical discharge machining
d. Electronic packaging materials and heat sink material
The specification and composition of tungsten alloy rods can be self-defined by customer.
