2500kgs Rolling Door Motor
- Shanghai
- Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | wangwei | |
| Model Number | JDD JD |
Product Description
Specifications
1.lifting Force:2500kg2.rolling door motor: three-phase
3.Packing:one set in two cartons
4.OEM Brand: wangwei
5.Type:JDD-JD
Rolling Door Motor Main Features
1.automatically open or close the doors by pressing relevant buttons
2.the doors are also workable under the operation of manual control equipment when there is no power supply.
3.can be remote controlled
4.with an overheat prevention device
5.with electronic anti-theft apparatus
6.Fireproof with strong power.
7.Low noise,small shaking.
Technical data:
| MODEL | Motor Power | Rated Voltage | Rated Current | Output Torque | Barrel / Tube DIA | Output Speed | Max Lifting | Max Lifting | Drive Chain |
| (W) | (V) | (A) | (N.M) | (mm) | rpm | Weight (Kgs) | Hight (m) | Pitch | |
| JDD-150-1P | 170 | 220V50Hz | 3 | 85 | 114 | 8.3 | 150 | 6.5 | 1/2" |
| JDD-300-1P | 250 | 220V | 2.5 | 210 | 140 | 5 | 300 | 6.5 | 5/8" |
| JD-300-3P | 200 | 380V | 1.2 | 210 | 140 | 5 | 300 | 6.5 | 5/8" |
| JDD-600-1P | 370 | 220V | 3.2 | 420 | 140 | 5 | 600 | 6.5 | 5/8" |
| JD-600-3P | 400 | 380V | 1.4 | 420 | 140 | 5 | 600 | 6.5 | 5/8" |
| JDD-800-1P | 400 | 220V | 3.5 | 650 | 165 | 3.9 | 800 | 6.5 | 5/8" |
| JD-800-3P | 450 | 380V | 2 | 650 | 165 | 3.9 | 800 | 6.5 | 5/8" |
| JDD-1000-1P | 450 | 220V | 4 | 820 | 165 | 3.9 | 1000 | 6.5 | 3/4" |
| JD-1000-3P | 470 | 380V | 2.2 | 820 | 165 | 3.9 | 1000 | 6.5 | 3/4" |
| JD-1500-3P | 500 | 380V | 2.5 | 1650 | 219 | 3 | 1500 | 6.5 | 1" |
| JD-2500-3P | 730 | 380V | 3.7 | 4370 | 273 | 3.3 | 2500 | 8 | 1" |
| JDD-4000-3P | 3000 | 380V | 6.7 | 8950 | 325 | 3.2 | 4000 | 8 | 1" |
| Related Products: | |||||||||
| .Digital remote controller for rolling shutter motor | |||||||||
| .Fireproof roller shutter door motor | |||||||||
| .Anti-chain rolling shutter door inertia break device | |||||||||
| .Sliding gate motor | |||||||||
| .Remote for door motor | |||||||||
| .Switch controller and push button controller | |||||||||
Remarks:1.Disadvantage: Price is not lowest.
Advantage: We are famous for rolling door motor in China and have our own patent. We ensure the quality(100%testing).Welcome your visiting, which is only 1.5hours driving to Shanghai.
2.Pls don't hesitate to contact us if you have any questions.
3.We can improve it as your designs without a large difference.
Mainly used in
