Product Details

Condition	New	Application	Beverage
Packaging Type	Bottles	Packaging Material	Wood
Automatic Grade	Automatic	Driven Type	Electric
Voltage	by order	Place of Origin	Jiangsu, China
Brand Name	MODERN PACK	Model Number	CGF
Certification	CE

Product Description

1.Direct connection technology between air conveyor and in-feeding starwheel is applied to replace in-feeding screw and conveying chain to ease bottle changing process with only to change few parts. Newly-designed bottle-separating grippers are assembled to starwheel.

2.Neck-hanging technology is applied in bottle transportation. Instead of traditional starwheel, we use neck-hanging gripper to make bottle-size-changing easily , without equipment height adjustment ,only few parts need to be adjusted .

3.Specially-designed rinser grippers which are made of stainless steel are firm and endurable, with no contact to screw part of the bottle to prevent second pollution.

4.High-speed, easily-cleaned filling valves with big flow volume are equipped with well CIP system and control system to rinse the equipment throughly.

5.splint of starwheel using twist descending way to simplify the process of bottle-size-changing. Only need to change arch board and starwheel ,within ten minutes.

bottle filling machine

Mineral Water filling machine 1.Capacity:2000-30000b/h 2.Bottle Specification:D=50-108mm H=170-340mm.

Mineral Water Production Line is suitable filling water,working steable with famous electrical components and working very stable.

Products Introduction: Juice Bottling Machine / Mineral Water Production Line-user:

Technical Data
Model	CGF12126	CGF18186	CGF24248	CGF323210
The number of Washing, Filling, Capping	12-12-6	18-18-6	24-24-8	32-32-10
Producing capacity; The number of bottle(600ml)/hour	3000-4000	6000-7000	8000-10000	12000-15000
Applicable bottle specifications (mm)	φ=50-108 H=170-340 330ml-2.25L
Pressure (kg/cm2)	2~3
Motor power (kw)	Main motor 1.5kw	Main motor 2.2kw	Main motor 3kw	Main motor 4kw
Outside vacuum pump power (kw)	0.75	1.1	1.5	2.2
Overall dimension (mm) (LxWxH)	2100x1400x2500	2460x1720x2650	3100x2100x2650	3500x2500x2650
Weight(kg)	2500	3500	4200	5500

Technical Data
Model	CGF404010	CGF484812	CGF606015
The number of Washing, Filling, Capping	40-40-10	48-48-12	60-60-15
Producing capacity: The number of bottle(600ml)/hour	18000-20000	22000-25000	28000-30000
Applicable bottle specifications (mm)	φ=50-108 H=170-340 330ml-2.25L
Pressure (kg/cm2)	2~3
Motor power (kw)	Main motor 7.5kw	Main motor 9.5kw	Main motor 12kw
Outside vacuum pump power (kw)	2.2	3	4
Overall dimension (mm) (LxWxH)	4600x1800x2650	5200x4500x3400	6500x4500x3400
Weight(kg)	6800	7600	9800

Zhangjiagang Modern Beverge Packing Machinery Co.,LTD. is a collection development, research, design, production and technical services and marketing into one professional engaged in the manufacture of mechanical equipment packages beverages, food packaging machinery equipment, high-tech enterprises. Companies have excellent development and design system experienced technical team, continually introducing Italy, and Germany abroad latest beverage packaging machine games, focusing on the reliability of the overall performance, development and improvement of their own products. Our company mangaerial concept is "cooperate honestly,base on the credit,be superior in quality".We would like to cooperate with all old and new customers to co-develop,establish long-term stable business relationship,and make a bright future together. Provide long-term mineral water, pure water (bpd) gasoline production lines on a tea, juice beverages hot, cold beverage production lines on a carbonic acid beverages bottled production line on a beverage tastes gasoline production lines on a purely Shengpijiu gasoline production lines on a yellow wine and white spirit, wine beverage production lines and various ancillary equipment, and the turnkey contract works.
