Home > Products > Stepper Motor > 3-phase 110BYG350C Microstep Stepper Motor
3-phase 110BYG350C Microstep Stepper Motor
- Beijing Shanghai Shenzhen etc
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Beijing, China | Brand Name | Microstep & Startshaphon | |
| Model Number | 110BYG350C | Phase | 3 | |
| Type | Hybrid | Certification | ISO | |
| Holding Torque | 18Nm | Current / Phase | 5.2A |
Product Description
Specifications
1.leading manufacturer of motor & driver in China2.famous trademark of "Microstep" & "Startshaphon" since 1992 in the world
110BYG350C
working environment:
-25 °C ~ +55 °C, 10~85% no dewing, no corrosivity, non-flammable and non-explosive, no electrical conductivity gas or liquid, no metal dust
insulation resistance: 500V DC 100MΩ Min
axial clearance: 0.1~0.3mm
radial run-out: 0.02mm max.
temperature rise: 85 °C max.
insulation strength: B
Model |
Type |
Current |
Driving | Max. Static |
Line Resistance |
Line |
Weight | Max. Starting |
Matching |
110BYG350A | 3-phase
|
5.2A |
AC220V | 8Nm | 2Ω | 15mH | 6.2kg | 270 rpm | MS-3H110M MSa-3H110M TD-3H522A |
110BYG350B | 12Nm | 1.5Ω | 16mH | 8.3kg | 240 rpm | ||||
110BYG350C | 18Nm | 1.5Ω | 20mH | 10.7kg | 210 rpm |
