Home > Products > Stepper Motor > 130BYG350C Microstep Stepper Motor
130BYG350C Microstep Stepper Motor
Negotiable
/ Set
1 Set(Min.Order)
- 1000 Set / Sets per Month
- Beijing Shanghai Shenzhen etc
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
3-phase 110BYG350A Microstep Stepper Motor
-
3-phase 110BYG350B Microstep Stepper Motor
-
3-phase 110BYG350C Microstep Stepper Motor
-
START NEW --28 segment-start Microstep step motor driver ###!!!!!!
-
28 segment-start Microstep step motor driver ###!!!!!!
-
NEW Release 28 segment-start Microstep step motor driver for step motor
Product Details
| Place of Origin | Beijing, China | Brand Name | Microstep & Startshaphon | |
| Model Number | 130BYG350C | Phase | 3 | |
| Type | Hybrid | Certification | ISO | |
| Holding Torque | 40Nm | Current / Phase | 6.8A |
Product Description
Specifications
1.leading manufacturer of motor & driver in China2.famous trademark of "Microstep" & "Startshaphon" since 1992 in the world
130BYG350C
working environment:
-25 °C ~ +55 °C, 10~85% no dewing, no corrosivity, non-flammable and non-explosive, no electrical conductivity gas or liquid, no metal dust
insulation resistance: 500V DC 100MΩ Min
axial clearance: 0.1~0.3mm
radial run-out: 0.02mm max.
temperature rise: 85 °C max.
insulation strength: B
Model |
Type |
Current |
Driving | Max. |
Line Resistance |
Line |
Weight | Max. Starting |
Matching |
130BYG350A |
3-phase hybrid |
6.8A |
AC220V | 27Nm | 0.9Ω | 11mH | 11kg | 210 rpm |
MS-3H110M |
130BYG350B | 33Nm | 1.1Ω | 14mH | 13kg | 200 rpm | ||||
130BYG350C | 40Nm | 1.4Ω | 20mH | 17kg | 190 rpm |
