High Quality Water Falling Tube Downpout Forming Machine
- Shanghai/Ningbo China
- T/T
You May Like
-
Hot Sale Water Downpout Forming Machine
-
Metal Water Pipe Downpout Roll Forming Machine
-
Steel Pipe Rolling Forming Machine
-
Steel Square Pipe Rectangular Tube Roll Forming Making Machine
-
Steel Pipe Rolling Metal Water Tube Forming Machine Price
-
Hot Sale Downspout Forming Machine for Water Falling Tube in China
Product Details
| Condition | New | Type | Other, cold metal roll forming machine | |
| Tile Type | Steel | Use | Other, wall and roof | |
| Production Capacity | 0-15m/min | Place of Origin | Zhejiang, China | |
| Brand Name | WILLING | Model Number | WLFM93-134 | |
| Power(W) | 7.5 kw | Voltage | as buyer's request | |
| Dimension(L*W*H) | 7800mm*1500mm*1500mm | Weight | 6000kg | |
| Certification | CE, ISO9001, GMC | Warranty | 12 month | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1. Thickness:0.4-0.6mm2. Strength: Q235-345Mpa
3. Material: galvanized or pre-painted steel sheet
4. Speed:0-15m/min
Water tube downpipe cold roll forming machine
1. Machine profile
As buyer's request
2. Machine layout
3. Main parameter
Material spec: | Color steel sheet; |
Thickness: | 0.4 mm to 0.6 mm |
Coil width: | depends |
Working speed: | 0-3m/min. (Nodal distance at 250mm) |
Cutting tolerance: | ±2mm |
Main motor power: | 4Kw |
Hydraulic station power: | 3.5Kw |
Decoiler | manual decoiler, max capacity 5000kgs |
Main roller qty: | about 16 stands but depends on last design |
Type of cutting: | Roll-formed and length-set cutting |
Main body dimension: | About 7800mm*1500mm*1500mm |
4. Machine picture
5. Working flow
Decoiling the sheet------Sheet guiding------Roll forming ------Measure length------Cutting the panel------Panels to the supporter
6. Standard equipment of machine
5tons passive uncoiler | 1set |
Pre-cutting equipment(Optional) | 1set |
Guiding Equipment | 1set |
Roll Forming Equipment | 1set |
Post Cut Equipment | 1set |
Hydraulic Station | 1set |
PLC Control Penal | 1set |
Supporter Table | 2sets |
