2000L water tank plastic extruction production blow molding machine best price

FOB Price

USD $220,000 - $260,000 / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Bottle
Plastic Processed	PE	Blow Moulding Type	Extrusion Blow Moulding
Automatic	Yes	Place of Origin	Shandong, China
Brand Name	sehenda	Model Number	SKJ
Certification	CE, ISO 9001: 2008. GB/T9001-2008	Warranty	1YEAR
After-sales Service Provided	Engineers available to service machinery overseas

1)Application: 200 to 1000L, 1-3 layer.
2) 1 year guarantee.
3) CE, ISO 9001: 2008. GB/T9001-2008
4)Fully automatic

2000L 1-3 layer blow molding machine

Technical specification
		SKJ2000L ONE LAYER	SKJ2000L DOUBLE LAYER	SKJ2000L THREE LAYER
Max. product volume	L	2000	2000	2000
Screw diameter	MM	140	120	110
Screw L/D ratio	L/D	30:1
Screw drive power	KW	132	90	90
Screw heating capacity	KW	30	40	60
Screw heating zone	ZONE	9	14	21
Output	KG/H	360	480	500
Oil pump drive power	KW	45
Clamping force	KN	1400
Mould open space	MM	3200
Mould thickness	MM	1220
capacity	L	70
Die head capacity	KW	40	45	48
No. of heating zone	ZONE	5
Die head material	38 CRMOALA(accumulator,lining,piston,die)
Control action	MITSUBISHI PLC
Blowing pressure	MPA	0.6
Cooling water pressure	MPA	0.2
size of machine	MM	To be confirmed	To be confirmed	To be confirmed
Weight of machine	MT	28	33	36

1. Appliction: For container and tank from 300 to 2000 liter, 1-3 layer

, also can be used to produce pallet, waste bin, road barrier, septictank,and so on.

2. Manpower: 2 new workers are enough for the whole production line, even both are female, and two weeks training are free of charge.

3. Output: 6-8pcs for 2000L 3 layer tank per hour, with weight 35-40kg, also the weight and thickness can be adjusted by you from 1mm to 10 mm.

4. Material: HDPE, HMWHDPE.

5. Certificate: CE, ISO9001:2008.

6. Main Markets: Asia, South Amereica, European.

30 years specializing in manufacturing huge blow moulding machine worth your trust .
