1000-liter Blow Moulding Machinery(Double Layers)

FOB Price

US$ 200,000 - 400,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Application	Other, Bottle, TANK
Plastic Processed	Other, PE, HDPE	Blow Moulding Type	Extrusion Blow Moulding
Automatic	Other, Yes, YES	Place of Origin	Shandong, China
Brand Name	Sehenda	Model Number	SKJ
Weight	60TON	Certification	CE 9000
Warranty	1 year	After-sales Service Provided	Engineers available to service machinery overseas

Technical Specification
No.	Item	Unit		SKJ1000L 2 LAYERS
1	Max. Product Volume	(L)		1000
2	Screw Diameter	(MM)		TWO Φ110
3	Screw L/D ratio	(L/D)		30 : 1
4	Screw Drive Power	(KW)		TWO 75
5	Screw Heating Capacity	(KW)		36
6	No. of Heating Zone	(ZONE)		12
7	Output	(KG/H)		320
8	Oil Pump Drive Power	(KW)		37
9	Clamping Force	(KN)		800
10	Mould Open Spacing	(MM)		2300
11	Mould Thickness	(MM)		1000
12	Capacity	(L)		35
13	Die Heat Capacity	(KW)		40
14	No. of Heating Zone	(ZONE)		4
15	Die Head Material	38CRMOALA(accumulator,lining, piston,die)
16	Control Action	MITSUBISHI PLC
17	Blowing Pressure	Mpa	0.6
18	Cooling Water Pressure	Mpa	0.2
19	Size of Machine	(LWH)(MM)	680053005200
20	Weight of Machine	(MT)	24
(The above data is for reference only)
