high speed horizontal rubber hose stainless wire braiding machine
- 20 Set / Sets per Month
- shanghai
- T/T
You May Like
-
shopping bag paper bag lace rope cord making machine twisting machine
-
High pressure rubber hose/water pipe/plumbing/stainless wire braiding machine
-
circular weft braiding machine for tuber sleeves
-
bobbin winding/warping machine/ winder
-
QX four heads semi-automatic winding machine
-
automatic winding machine coil rewinder bobbin thread winding
Product Details
| Place of Origin | Jiangsu, China | Brand Name | Xuzhou Qixing | |
| Model Number | QX188 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Model | 16 spindles | 24 spindles | 36 spindles | 48 spindles | 64 spindles | 96 spindles | 112 spindles |
Material size | Wires: Ø0.16mm-----0.50mm Stainless wires: Ø0.20mm-----0.50mm | ||||||
Bobbin size | Ø83*200mm Inner diameter 31mm. total length 208mm. | ||||||
Strands number | 4-12 | ||||||
RPM of spindle | 30RPM | 23.3RPM | 15.2RPM | 12.1RPM | 9.07RPM | 6.05RPM | 5.19RPM |
Spindle tension | 3.5kg----13kg | ||||||
Products diameter | 22mm | 30mm | 45mm | 78mm | 145mm | 228mm | 335mm |
Motor | 3HP/4P | 5PH/4P | 7.5HP/4P | 10HP/4P | 15HP/4P | 25HP/4P | 30HP/4P |
Machine weight | 2.5t | 3.1t | 4.2t | 5.3t | 6.7t | 8.5t | 9.7t |
