back pack water mist spraying extinguisher

Specifications

water mist spraying extinguisher

Water mist fire monitor is the use of pressure water, formation water mixed with certain pressure fire extinguishing media, can't fire extinguishing purposes (see chart ), especially applicable to save city residential area, tunnel, bazaar, high road, high-rise buildings, vehicles and other fires, especially in the initial stage of fire fighting and rescue effect in the process of the apparent.

Assembly Including:

Air Cylinder: 3L

Storage Buckets: 9L

Regular Water Hose

Nozzle

 Its Accessories

DC continuous injection item and spray continous injection time are all>25s.

DCinjection distance is >17m,spray injection distance is >8m.

Weight:23kgs

outer Packing Size:51*32*69cm

operation method :

1. Screw down the valve of the air cylinder
2. Double-press the switch of the fire gun
3. Pressing the snuffle valve of the storage bucket until there is no air
4. Open the valve of the storage bucket
5. Mix the foam and water according to the certain proportion (first water, then foam), pulling the mixed liquor into the storage bucket, and screw down the valve
6. Open the valve of the air cylinder
7. Screw down the nozzle of the fire gun, then spraying
8. The nozzle from the gun at the right angles, spraying direct current
