Automatic Carton Box Opening Machine GPK-40H30

Automatic Carton Box Opening Machine GPK-40H30

Description

GPK-40H30 is a horizontal type carton forming and bottom sealing machine. cam gear driving. PLC control. The carton erecting speed can be adjusted on the touch screen. Easy carton storage system, no need to stop the machine while adding the carton. Carton size can be adjust manually in 1 or 2 mins. Safety protect cover, E-stop and error alarm. Easy to operate and maintain. Machine can combine with our carton sealers, shrink wrap machines, strapping machine etc. to create to fully auto packing line.

Technical Parameter:

Model GPK-40H30

Production speed 30ctns/min

Carton size(mm) L250-510xW190-400xH120-400

Power Supply 380V,3P, 746W

Air compressing 5kg/cm³

Air consumptions 300NL/MIN

Machine dimension L2372xW1210xH1820mm

Machine weight 1000KG

Adhesive tape width 2“,2.5”

Configuration:
1. Good quality bearing.
2. CHIN safety switch,Double insurance, safety and reliable.
3. Italy imported material Belt, durable in use
4. Cylinder: Japan SMC, Germany FESTO
5. SIEMENSPLC and HIMI control system
7. Leutze Sensor from Germany, accurately and sensitive.
8. SEW Motor from Germany.
9. Japan SK-12Cutter, stainless steel cutter, sharp and durable
10. Schneider Low-voltage apparatus from France
11. Japan Mitsubishi/ Germany SIEMENS Transducer

Options:
1. Color selectable.
2. Full protective cover and safety doors.
4. opposite erecting direction.
5. 220V 3 Phase available.
6. Plug type selectable.
7. Tape lack and break Alarm.
8. Stainless steel.
9. Customized table height.
