Automatic Tablets Filling Machine For Glass Bottles

The device for automatic frequency conversion type double counting ( grain ) machine is a new concept for designing a new algebraic tablets ( tablets) machine, widely used in pharmaceutical, food, chemical industry, the sphere pellets, soft and hard capsules or sheet goods automatic counting and filling, this machine has reasonable design, simple operation, easy maintenance, can be single or line. This equipment is in full compliance with GMP requirements.

Characteristic:

1. Small noise, stable, accurate count down.

2. With no bottle ,which stop falling film optically controlled device, no bottle automatic shutdown.

3 .Principles of advanced design, reasonable and compact structure.

4. Frequency control, production speed controllable.

5. All electrical components are all well-known brands.

6. The equipment surface are adopted 304 stainless steel production, in full accordance with the GMP standard production.

Technical parameters:

Applicable specifications: 15-500ml

Production capacity :10-60 bottles / min ( according to type of container .)

Falling plate specifications:Φ3m- Φ25mm

Filling precision :Less than ± 1%

Power: 220V/50Hz

Power:1KW

Tablets plate diameter: 467mm ( organic glass ) 476 ( laminate )

Machine weight: 580KG

Dimension: 2400 x 1300 x 1400mm

Samples:
