Klinger Quality Level Gauge Glass for Sale
- qingdao
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Klinger Quality Aluminosilicate Reflex Level Gauge Glass
-
Klinger Quality Aluminosilicate Level Gauge Glass
-
Klinger Quality Wholesale Borosilicate Water Level Gauge Glass
-
Klinger Quality Water Level Indicator With Boiler Level Gauge Glass
-
Klinger Quality Water Level Controls Gauge Glass
-
Klinger Quality Water Level Gauge Optical Glass
Product Details
| Place of Origin | Shandong, China | Brand Name | Winton | |
| Model Number | A1-A9 |
Product Description
klinger quality level gauge glass for sale
klinger quality level gauge glass for sale
Its made from Borosilicate, it is used in lever gauge in boiler for water position.
It is also named: Reflex Gauge Glass, Sight glass, Reflex Glasses
Reflex sight glass, Spares For level Gauge
1.Gauge glass mostly divide into these series:
Clear gauge glass
Reflext gauge glass
1) Three tendons (four grooves)
2) Two tendons (three grooves)
2.It is also named:
Reflex Gauge Glass, Sight glass, Reflex Glasses
Reflex sight glass, Spares For level Gauge.
klinger quality level gauge glass for sale | |
![]() | Three tendons (four grooves)
Size:340 x 34(30) x 17mm 320 x 34(30) x 17mm, 220 x 34(30) x 17mm, 140 x 34(30) x 17mm,
Working pressure: 4.0MPa |
klinger quality level gauge glass for sale
Size
340 x 34(30) x 17mm , 320 x 34(30) x 17mm , 280 x 34(30) x 17mm
250 x 34(30) x 17mm , 220 x 34(30) x 17mm , 190 x 34(30) x 17mm
165 x 34(30) x 17mm , 140 x 34(30) x 17mm , 115 x 34(30) x 17mm
Material
Borosilicate glass
Main Composition
SiO2 B2O3 Na2O+K2O Al2O3
81 13 4 2
Chemical Property
Hydrolytic resistance at98° CISO719-HGB 1
Hydrolytic resistance at121° CISO720-HGA 1
Acid resistance ClassI SO1776-First Class
Usage
It is used in lever gauge in boiler for water position.
klinger quality level gauge glass for sale
Level Gauge Glass Physical Property | |
| Testing Item | Standard Rules |
1. Appearance | 1) Air bubble: |
2. Colour and Lustre | It should be no color and transparent,and with its self tine green is allowed. |
3. Water-resistance | Cooked in the water for 5 hours,then weigh up ,then titration with 25ml 0~31 ug/g |
4. Alkali-resistance | Cooked in the 0.5N NaoH for 3 hours,then Weigh up,weightlessness should be ≤75 mg/dm2 |
5. Temperature-resistance impacts capability | Put it into electric cooker,keep for 7min under the temperature of 260±1,then,put into the water of 20±1,it should not crack |
6. Bend-resistance | ≥80 MPa |
klinger quality level gauge glass for sale
klinger quality level gauge glass for sale
1. Providing technical consultation.
2. Special packaging according to request.
3. Providing related qualification documents.
4. Accepting customer's audit on site.
5. Providing shuttle bus service when visiting our factories.
6. Solving the quality matter on production line, providing technical inspection.
7. Solving customer's complaints in time and making advancement.
klinger quality level gauge glass for sale
klinger quality level gauge glass for sale
| sight glass | Al-si gauge glass |
cobalt glass | gauge glass gasket | road stud |
