Preformed Ground Wire strain clamp
- Any port in China
- T/T Credit Card PayPal
You May Like
Product Details
Place of Origin | Jiangsu, China | Brand Name | OCEAN | |
Model Number | ORN |
Product Description
Specifications
Preformed Ground Wire strain clamp1.High intensity;
2.Well corrosion resistance;
3.Easy installation;
Preformed Ground Wire strain clamp
Purposes & Characteristics
The preformed ground tension set is used in the groundwire installation of tower and pole in overhead.
The special design predigest structure of preformed ground tension set.After installation,the pipe structure formed by the two legs of the preformed line would enlace the conductor naturely and would produce a great holding stength.The full set tension sets include preformed rod,thimble and other linking fitting are all rivet on the pole and tower.
Materials
1.Strand ground wire,and clamp uses galvanized steel wire;
2.Aluminum steel ground wire,good conductor ACSR, clamp use aluminum steel wire.
Preformed ground tension set(For strand wire)
Type | Standard type | Suitable diameter(mm) | Suitable conductor type(mm2) | Clamp Length(mm) | Color Code |
ORN 3100 | NL-25/G | 6.60 | 25 | 636 | yellow |
ORN 3101 | NL-35/G | 7.65-7.95 | 35 | 712 | black |
ORN 3102 | NL-50/G | 8.95-9.30 | 50 | 903 | green |
ORN 3103 | NL-70/G | 10.82-11.10 | 70 | 1018 | blue |
ORN 3104 | NL-95/G | 12.50 | 95 | 1335 | red |
ORN 3105 | NL-100/G | 13.00 | 100 | 1335 | green |
ORN 3106 | NL-120/G | 14.00 | 120 | 1464 | blue |
Preformed ground tension set(For ACS)
Type | Suitable diameter(mm) | Clamp Length(mm) | Color code |
ORN-4100 | 4.42-4.60 | 465 | blue |
ORN-4106 | 5.56-5.85 | 540 | green |
ORN-4107 | 5.86-6.00 | 540 | yellow |
ORN-4108 | 6.01-6.28 | 610 | black |
ORN-4109 | 6.29-6.56 | 565 | purple |
ORN-4110 | 6.57-6.84 | 580 | red |
ORN-4111 | 6.85-7.12 | 630 | blue |
ORN-4112 | 7.13-7.40 | 630 | green |
ORN-4113 | 7.41-7.67 | 640 | yellow |
ORN-4114 | 7.68-7.95 | 680 | black |
ORN-4115 | 7.96-8.23 | 680 | purple |
ORN-4116 | 8.24-8.54 | 680 | red |
ORN-4117 | 8.55-8.69 | 750 | blue |
ORN-4118 | 8.70-9.02 | 775 | green |
ORN-4119 | 9.03-9.25 | 825 | yellow |
ORN-4120 | 9.26-9.63 | 820 | black |
ORN-4121 | 9.64-10.01 | 850 | purple |
ORN-4122 | 10.02-10.39 | 890 | red |
ORN-4123 | 10.40-10.82 | 920 | blue |
ORN-4124 | 10.83-11.23 | 950 | green |
ORN-4125 | 11.24-11.66 | 990 | yellow |
ORN-4126 | 11.67-12.04 | 1010 | black |
ORN-4127 | 12.05-12.55 | 1030 | purple |
ORN-4128 | 12.56-13.08 | 1130 | red |
We could design as customs' needs,for more information,please contact us freely.
Just tell us the conductor diameter for quotation.
