Home > Products > EN877 CAST IRON PIPES, FITTINGS, COUPLINGS > KTN-CHA type stainless steel coupling
KTN-CHA type stainless steel coupling
USD $1.15 - $12.66
/ Piece
1 Piece(Min.Order)
- TIANJIN XINGANG
- T/T
You May Like
Product Details
| Material | Stainless Steel | Technics | Other, punching welding | |
| Type | Coupling | Place of Origin | Hebei, China | |
| Model Number | KTN-CHA type stainless steel coupling | Brand Name | CASITING | |
| Connection | Other, flexible | Shape | Equal | |
| Head Code | Other, round |
Product Description
Product Description
This coupling is used for connecting cast iron pipes and cast iron fittings comply with DIN EN877 and BS EN877, flexible joint.
1) Material of body: SS304 or SS316
2) Material of bolt: SS304 or SS316 or Galvanized Carbon Steel
3)Standard: mechanical of stainless steel coupling body conform to BS6087, EPDM rubber seal conform to ASTM C564
4) Two or three halves
5) Application area: rainwater&waste water pipelines, pressurized pipes
1) Material of body: SS304 or SS316
2) Material of bolt: SS304 or SS316 or Galvanized Carbon Steel
3)Standard: mechanical of stainless steel coupling body conform to BS6087, EPDM rubber seal conform to ASTM C564
4) Two or three halves
5) Application area: rainwater&waste water pipelines, pressurized pipes
| No. | size | pcs/box | box size | kg/box | structure | |
| inch | mm | (cm) | ||||
| 1 | 1.5" | DN40 | 100 | 40*29*32 | 15.6 | 2halves |
| 2 | 2" | DN50 | 100 | 46*33*33 | 17.4 | 2halves |
| 3 | 2.5" | DN70 | 100 | 70*38*30 | 20.2 | 2halves |
| 4 | 3" | DN75 | 100 | 58*42*31 | 22 | 2halves |
| 5 | 4" | DN100 | 50 | 54*39*34 | 13.8 | 3halves |
| 6 | 5" | DN125 | 50 | 72*53*39 | 20 | 3halves |
| 7 | 6" | DN150 | 50 | 72*53*39 | 21.8 | 3halves |
| 8 | 8" | DN200 | 12 | 72*39*29 | 10.4 | 4halves |
| 9 | 10" | DN250 | 10 | 62*62*46 | 17 | 4halves |
| 10 | 12" | DN300 | 4 | 72*39*32 | 8.2 | 4halves |
The matching with KTN-CV CLAMP
