Ceramic roller
- 15000 Ton / Tons per Month
- Qing Dao
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin | Shandong, China | Type | Ceramic Rollers | |
| Application | Industrial Ceramic | Material | Alumina Ceramic | |
| Model Number | CERAMIC ROLLER | Brand Name | FAME RISE |
Product Description
Specifications
We can supply all kind of Ceramic roller , ceramic fiber paper, ceramic fiber rope.Ceramic roller description:
Ceramic roller made from refractory ceramic fiber, attending inorganic and suitable organic binders, High temp. resistant
Ceramic fiber board made from refractory ceramic fiber, attending inorganic and suitable organic binders.The mixture is vacuum processed into boards that keep good mechanical strength after heating. These products can be manufactured using three basic
fiber types ranging from 1000, 1260, 1400 centigrade degree Ceramic roller can be used for internal lining of furnace with high strength and resistance to high gas flow velocity
Ceramic roller technical data:( stardand type) :
1. Specification temp ( oC ): 1260
2. Continuous working temperature( oC ): 1000
3. Color: white
4. Density (kg/m3): 260-350
5. Rate of liner (%) (24h.128kg/m3): -3 (1000 oC )
6. Rate of thermal conductivity (W/m. K) (285kg/m3): 0.085(400 oC) 0.132(800 oC) 0.180(1000 oC)
7. Tensile strength (Mpa)(Strength 10%): 0.5
8. Chemical Composition: (%) AL2O3: 45-46 AL2O3+SiO2: 96-97 Fe2O3:
9 Na2O+K2O: ≤0.5
Standard Ceramic roller application:
1.Glass tank side, end wall and port neck
2.Glass tank wall and port neck insulation
3.Heat shields
4.High mechanical stress areas
Ceramic roller data sheet:
| characteristics | Items | Types | ||||
| SS-C-1100 | SS-C-1200S | SS-E-1250 | SS-F-1300 | |||
| Physical Properties | Bulk Density(g/cm3) | 2.3~2.5 | 2.5~2.7 | 2.5~2.7 | 2.5~2.7 | |
| Straightness | <0.07%*L | <0.07%*L | <0.07%*L | <0.07%*L | ||
| Apparent Porosity(%) | 20~25 | 17~22 | 17~22 | 15~20 | ||
| Water Absorption(%) | 8~10 | 6~8 | 6~8 | 6~8 | ||
| Bending Strength (Mpa) | Room Temp. | 40~50 | 45~55 | 45~55 | 60~67 | |
| High Temp.(1300°C) | >20 | >30 | >40 | >40 | ||
| Thermal Expansion Coefficient (×10-6/°C)(25-1000°C) | 5.5~5.7 | 5.7~6.0 | 5.6~5.9 | 5.7~6.0 | ||
| Thermal Shock Resistance | Good | Excellent | Very good | Very good | ||
| Max.Working Temp.(°C) | 1100 | 1200 | 1250 | 1300 | ||
| Chemical Composition | Al2O3(%) | 65~68 | 74~76 | 74~76 | 70~72 | |
| SiO2(%) | 25~27 | 22~24 | 22~24 | 21~23 | ||
| ZrO2(%) | - | - | - | 4~7 | ||
| Application | Roller Kiln | × | × | × | × | |
| Glazed Wall Tile | × | × | × | × | ||
| Glazed floor Tile | × | × | × | × | ||
| Porcelain Tile | × | × | × | × | ||
| Tableware | × | × | ||||
| Magnetic Ceramics | × | |||||
| Sanitary Ceramics | × | |||||
| Hi-tech Ceramics | ||||||
| Specification | Ø21-70mm,Length up to≤ 4500mm | |||||
2,
| Dia.(mm) | Length(mm) | Dia.(mm) | Length(mm) |
| Φ65 | 4190-4380 | Φ45 | 3790-3980 |
| 3990-4180 | 3590-3780 | ||
| 3790-3980 | 3290-3580 | ||
| 3590-3780 | 2990-3280 | ||
| 3390-3580 | 2690-2980 | ||
| 3190-3380 | 2490-2680 | ||
| 2690-3180 | ≤2480 | ||
| ≤2680 | Φ42 | 3290-3580 | |
| Φ60 | 4190-4380 | 2990-3280 | |
| 3990-4180 | 2690-2980 | ||
| 3790-3980 | 2490-2680 | ||
| 3590-3780 | ≤2480 | ||
| 3390-3580 | Φ40 | 2890-3180 | |
| 3190-3380 | 2590-2880 | ||
| 2690-3180 | 2490-2580 | ||
| ≤2680 | ≤2480 | ||
| Φ55 | 4190-4380 | Φ35 Φ33.7 Φ32 | 2890-3180 |
| 3990-4180 | 2590-2880 | ||
| 3790-3980 | 2490-2580 | ||
| 3590-3780 | ≤2480 | ||
| 3390-3580 | Φ30 Φ27 | 3090-3380 | |
| 3190-3380 | 2790-3080 | ||
| 2690-3180 | 2490-2780 | ||
| ≤2680 | ≤2480 | ||
| Φ50 | 4190-4380 | Φ25 Φ21 | 2790-3080 |
| 3990-4180 | 2490-2780 | ||
| 3790-3980 | 2290-2480 | ||
| 3590-3780 | ≤2280 | ||
| 3390-3580 | Other size according the request of customers'. | ||
| 3190-3380 | |||
| 2690-3180 | |||
| ≤2680 | |||
The package of the Ceramic roller .
Our service of Ceramic roller :
We can guarantee the quality of the Ceramic roller with the competitive price. We will try our best to satisfied the requirement of the customer about the Ceramic roller products. We do not want to do the one-shot business of the Ceramic roller . We also can provide some samples of the Ceramic roller products.
