- Tangshan Zhifu Plastic Machinery Co., Ltd.
-
Tangshan, Hebei, China
- Main products: Inline Flat Dripper Irrigation Tape Machine, Single Blade Labyrinth Type Drip Irrigation Tape Machine, Micro-Spray Irrigation Tape Machine, Melt Flow Type Drip Irrigation Tape Machine, PE Plastic Pipe Machine, Inline Round Dripper Irrigation Pipe Machine
Home > Products > Drip irrigation pipe machine > melt flow type drip irrigation plastic hose making machine
melt flow type drip irrigation plastic hose making machine
- Xingang(Tianjin)
- T/T
You May Like
-
labyrinth type drip irrigation tape plastic making machine CE
-
High Speed Single Blade Labyrinth Type plastic watering Drip Irrigation Tape Making Machine
-
agricultural inline flat dripper drip irrigation pipe plastic machine
-
CE mosaic flat dripper farm irrigation system
-
melt flow drip irrigation tape equipment
-
high speed single labyrinth drip irrigation plastic tape machinery
Product Details
| Condition | New | Application | Pipe | |
| Plastic Processed | PE | Screw Design | Single-screw | |
| Automatic Grade | Automatic | Place of Origin | Hebei, China | |
| Brand Name | ZFSJ | Model Number | SJLY-65 | |
| Voltage | 380V | Power(W) | 68KW | |
| Dimension(L*W*H) | 9*5*3.5M | Weight | 3000KG | |
| Certification | CE | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
Specifications
1, diameter:16mm2, thickness:0.2-0.3mm
3, working pressure:0.05-0.07Mpa
4,pressure:0.05-0.07
5,material:PE
melt flow type drip irrigation plastic hose making machine
machine parameter
Model | SJLY-65 |
Specification of final product | φ16mm |
Production speed | 70 m/min |
Main driving power | 30kw |
Max.extruding capacity | 60kg/h |
Heating power | 26kw |
Filter changing way | durable filter (patent) |
Driving power of shaping wheel | 7.5kw |
Driving power of tractor | 1.5kw |
Winding motor | torque motor 12N.m*2 |
Water consumption | 2.5m³/h |
Air consumption | 0.2m³/h |
Installation power | 68kw |
Overall dimension(L*W*H) | 9M*5M*3.5M |
patent and certificate
Item | Certificate /Patent type |
Melt-flow type drip irrigation tape making machine | CE |
ISO | |
The first researcher in China | |
Durable filter | Utility New Type Patent |
Melt-flow type drip irrigation tape | Appearance Design Patent |
Parameters
| Nominal ID (mm) | Nominal wall thickness (mm) | Working pressure (Mpa) | Flow rate (L/H) | Space between drippers (mm) | Length of roll (m) |
Data | 16,20 | 0.2-0.3 | 0.05-0.07 | 0.5-1.5 | 100,150,200,300adjustable according to customer’s demand | 2000 |
workshop
customer show
