Professional Hobbywing Platinum 30A OPTO PRO Brushless ESC for Quadcopter

FOB Price

USD $9.99 - $11.99 / Piece

10 Pieces(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Professional Hobbywing Platinum 30A OPTO PRO Brushless ESC for Quadcopter

Features

High performance microprocessor, best compatibility with all kinds of motors, highest driving efficiency.
Optimized for multi-rotor aircraft.
Smooth, linear, quick and precise throttle response.
Multiple protection features: Low-voltage cut-off protection / Over-heat protection / Throttle signal loss protection.
The firmware of the ESC can be updated through the built-in USB adapter in the Professional LCD Program Box.
User programmable.
Multiple program methods supported: transmitter stick, Digital LED Program Card, Multifunction LCD Program Box, Professional LCD Program Box, PC software. Very easy to program the ESC at home or at the flying field.

Specifications

Specifications

Output	Continuous 30A, burst 40A up to 10 seconds
Input Voltage	2-6 cells lithium battery or 5-18 cells NiMH battery
BEC	Not available
Refresh rate of the throttle signal	50Hz to 432Hz
Max Speed	210000rpm for 2 Poles BLM, 70000rpm for 6 poles BLM, 35000rpm for 12 poles BLM. (BLM = BrushLess Motor)
Size	55mm (L) * 25mm (W) * 12mm (H)
Weight	31g
