The Leading Market for High Quality and Low Price Medical Patient Monitor

 The leading market for high quality and low price medical  patient monitor

1.1 Safety Classifications

Item Specification
MDD classification Class IIb
Anti-electroshock degree Class I equipment with internal power supply
Anti-electroshock degree TEMP/SpO2/NIBP: BF
ECG/RESP: CF
Explosion proof level Ordinary equipment,without explosion proof
Harmful liquid proof degree IPX1
Working system Continuous running equipment
Equipment type Portable

1.2 Applicable Standards

Medical Device Directive 93/42/EEC
EN60601-1:2005 or IEC60601-1:2005, Medical Electrical Equipment, Part 1: General Requirements for Safety
EN60601-1-1 or IEC60601-1-1, Medical Electrical Equipment, Part 1-1: General Requirements for Safety, Collateral Standard: Safety Requirements for Medical Electrical Systems
IEC60601-1-4, Medical Electrical Equipment, Part 1-4: General Requirements for Safety, Collateral Standard: Programmable Electrical Medical Systems
IEC60601-2-49, Medical Electrical Equipment, Part 2-49: Particular Requirements for the Safety of Multifunction Patient Monitoring Equipment
IEC 60601-1-2:2007, Electromagnetic Compatibility, Medical Electrical Equipment
ISO 21647:2009, Medical electrical equipment — Particular requirements for the basic safety and essential performance of respiratory gas monitors

1.3 Environment

Temperature
Working 0 ~ 40 ℃
Storage -20 ~ 50 ℃
Humidity
Working 15 % ~ 90 %
Storage 15 % ~ 90 % (no coagulation)
Atmospheric pressure
Working 86.0 kPa ~ 106.0kPa;
Storage 86.0 kPa ~ 106.0kPa

1.4 Lead mode

5 Leads: RA,LA,LL,RL,V; Lead mode: I, II, III, AVR, AVL, AVF, V
1.11.4 Gain
×2.5mm/mV, ×5.0mm/mV, ×10mm/mV, ×20mm/mV
1.11.5 Sweep speed
12.5mm/s, 25mm/s, 50mm/s
