Home > Products > X-ray baggage machine > Factory Outlets Good Quality Safety for Security x Ray Baggage Scanner
Factory Outlets Good Quality Safety for Security x Ray Baggage Scanner
US$ 1 - 8,000
/ Piece
1 Piece(Min. Order)
- SHENZHEN
- Credit Card PayPal
You May Like
-
X Ray Baggage Scanner Metal Detector for Conveyor Belt for Security Checkpoints / School
-
Mid-size X Ray Luggage Inspection Machine for Airport Security Check System
-
PD-5030 x Ray Inspection Luggage Scanner Baggage Scanner
-
Stainlesss Steel X-ray Detector for Airport Luggage Inspection
-
Elegant Shape Baggage Metal Detector,x Ray Baggage Scanner,x-ray Scanner Airport
-
X-ray Luggage Scanner PD100100 Airport x Ray Luggage Scanner
Product Details
| Place of Origin | Guangdong, China | Brand Name | KATM | |
| Model Number | PD-5030 |
Product Description
Product Description
X-Ray Baggage Inspection Machine
Model: PD5030C
General Specifications
Tunnel Size : 500 (W) * 300 (H) mm
Conveyor Speed: 0.22m/s
Conveyor Max Load: 150 kg
Single inspection dosage: < 1.32μGy
Wire Resolution: 40AWG (0.0787mm metal line)
Steel Penetration: 43mm
Film Safety: For ISO 1600
X-RAY GENERATOR
Orientation: Upward
Tube Current:0.4~1.2mA(adjustable)
Anode Voltage:100~160KV(adjustable)
Angle: 80°
Generator cooling/working periods:
Sealed oil bath with forced air/100%
OPERATING ENVIRONMENT
Storage Temperature: -20oC to 60oC
Operating Temperature: 0oC to 45oC
Relative Humidity: 20 to 95% non-condensing
System Power: 220 VAC (±10%) 50±3HZ
Power wastage: 1.0 KW (Max)
Noise<65DB
X-RAY Sensor: L-shaped array detector, 24bit
Dual energy
Packaging & Shipping
Package Dim. with wooden case L*W*H (mm) Net weight (KG) Gross weight(KG) Volume (CBM)
1880*880*1430MM 400 KG 425 KG 2.265 CBM
1880*880*1430MM 400 KG 425 KG 2.265 CBM
