Fine Quality Digital Schmidt Hammer HT225D
- Shanghai or Other Port in china
- Credit Card
You May Like
Product Details
| Place of Origin | Shanghai, China | Brand Name | SX | |
| Model Number | HT-225 | Power | Other, Manual | |
| Usage | Other, Cement Testing Machine, suitable in field use or lab |
Product Description
Digital Schmidt Hammer HT225D
Application:
This instrument applies to non-destructive testing about the inspection strength of sintered common brick, at the same
time, it is also suitable for light bone structure concrete and other light bone materials strength inspected.
Specifications:
Measuring strength ranges: 10-60 MPa
Normal impact energy: 2.207 J(0.225Kgf.m)
Strike hammer stroke: 75 mm
The consistency of sample displayed value : ≤ ± 0.5 ( different value between digiatal sampling output value and pointer readings
Measuring rang : from 10-70N/MM²
The friction force of pointer slider: 0.5±0.8 N
Spherical radius of strike rod: 25 mm±1 mm
The rebound values calibrated on steel anvil:80±2
Display : 16bits True colors, 176*220 resolution, 5 levels of backlighting, adjustable
Power : 3.6V, 1300Mah LITHIUM batteies , matching charing adapter 5V/2A, Max backlight, turn off speech cases,
continuous working 13hours
Packing detail :
Dimensions: Dia. 54×278 mm
Weight approx: 1 Kg
Purchasing Notes :
1. about packing , we should put 5sets into one carton, so we suggest you choose 5sets as trial order
2. the model is economical and popular model, we have been exporting more than 500sets to dfferent countries,
