High Sensor Conveyor belt metal detector, needle detector for costume industry

Detailed Product Description

JZQ-86K needle detector is the promoted model of JZQ-86A/86B,made of aluminum alloy,double circuits detecting,four zone design,will greatly improve the detecting and leakage functions of the detector ,and will suitable in toy and costume industry.

Scope of Application:

It is mainly used to detect break needle,knife,metal splinters that lord or drop in raw materials and products in the field of cosume,wollen goods,neckties,chemical industry,leather,food and so on

Zoning Broken Portable Industrial Food Metal Detectors 220v 50hz

 Function :

a.  Japanese technology, computer chip integrated circuits, aluminum shell.
b.  With high sensitivity and Super anti-jamming capability, can adapt to long-term use,

according to the requirement to use test results up to 100%

c.  Using the power of built-in fuse socket Insurance.

d.  12 adjustable sensitivity. Sound intensity adjustable volume requirements for different sites

e.  Four detection Zoning can be used independently and will not affect each other.

f.  Double inductor, triangle detecting area cover without blind section. the sensitive effect is up

30% than normal flat form needle detector

Parameters
Body Material Aluminum; Al alloy
Dimensions 70 × 40 × 7CM (length × width × height); detection zone 50 × 25CM (L × W)
Packing size 75 × 48 × 12CM (length × width × height); supply voltage AC 220V ± 10%
Weight Approx 13.5Kg; frequency 50HZ
Power 30W; Alarm sound and light alarm, alarm volume adjustment fourth gear
Sensitivity of surface 0.8mm iron ball, half needle, and a staple at the altitude of up to 6 cm

(from the surface of the more recent detection of the higher detection sensitivity);

Electrical Source: 220 V 50 HZ

Power: 30 W

Size: 75cm(L) * 48cm(W) * 12 cm (H)

Detecting zone : 50*25cm

Detecting zones : 4 detecting areas

Size: 75 cm(L) * 48 cm (w)* 12 cm(h)

Detecting zone: 50*25 cm.
