PV Double Glass Solar Panel Building Integrated Photovoltaic System

Data Parameter:
Dimension of BIPV: 1000 X 1700mm
Solar Cell: (6 X 12)72pcs, 125 X 125mm Monocrystal
Peak Power(Pm): 180W
Maximum Power Voltage(Vmp): 36.50V
Maximum Power Current(Imp): 4.93A
Open circuit Voltatge(VOC): 44.70V
Short Circuit Current(ISC): 5.23A
Transparence: 40%
Glass Thickness: 4mm + PVB + cell + PVB + 4mm
Thickness of Module: 10mm+/-1mm
Weight: 45kgs

Why Choose us

Professional manufactures, strict quality control & full automatic production equipment

Professional salesmans, who have more than 10 years international business experiences

High vonversion efficiency, high transmisson rate, low iron tempered anti-reflecting/coating film 3.2mm glass

Anti-aging & high visosity EVA

High frame resistant & double-sided flourine TPT

Anodized aluminum alloy high thickness frame

3 or 6 bypass diodes, 90mm 4m2 cable, MC4 connectors & waterproof junction box

Long life, easy installation, high wind and hail impact resistance etc advantage

ISO 9001:2008/ISO14001:2004, CE/TUV/CEC/IEC 61215/IEC61730

10 years warranty on workmanship,10 years 90% & 25 years 80% Of The Power Output
