Mder Hot Sale Wire Reinforced High Pressure Rubber Flexible Hose Factory
US$ 4 - 4
/ Meter
10000 Meters(Min. Order)
- Tianjin
- T/T
You May Like
-
Mder High Pressure Rubber Oil Resistant Hose Manufacturers
-
Mder Construction Machinery Industrial Hydraulic Rubber Hose
-
High Quality High-quality Oil Hydraulic Rubber Hose Manufacturer From China
-
High Quality Flexible Sae/din Hydraulic Rubber Hose
-
Flexible Rubber Hose Pipe and Fittings Assembly Used for Oil
-
DIN Series Hydraulic High Pressure Rubber Hose 70mpa Hydraulic Pressure Hose
Product Details
| Place of Origin | Hebei, China | Brand Name | Mder | |
| Model Number | SAE |
Product Description
Mder hot sale wire inforced high pressure rubber flexible hose factory
Recommended for:High pressure hydraulic oil lines for applications with crude oils, fuel oils,lubricating oils and gasoline.
Tube:Black, oil resistant,oil resistant synthetic rubber
Reinforcement: four plies of spirally wrapped high tensile steel wire.
Cover:Black, oil and weather resistant synthetic rubber
Temperature: -40℃ -- +100℃(-40℉ -- +212℉)
| M-RS9 (SAE 100 R9) High pressure, four spiral steel wire reinforced hydraulic hose | ||||||||||||||||
| Type | SIZE | SIZE | ID | WD | OD | WP | BP | min BR | WT | |||||||
| A TYPE | AT TYPE | |||||||||||||||
| mm | inch | Min | Max | Min | Max | Min | Max | Max | Mpa | Psi | Mpa | Psi | Inch | mm | Kg/m | |
| RS9-06 | 10 | 3/8 | 9.3 | 10.1 | 16.9 | 18.0 | 20.6 | 22.2 | 21.1 | 31.5 | 4570 | 126 | 18270 | 4.92 | 125 | 0.70 |
| RS9-08 | 12.5 | 1/2 | 12.3 | 13.5 | 19.4 | 21.0 | 23.8 | 25.4 | 24.3 | 28 | 4060 | 112 | 16240 | 7.09 | 180 | 0.83 |
| RS9-12 | 19 | 3/4 | 18.6 | 19.8 | 26.6 | 28.2 | 30.6 | 32.2 | 31.9 | 21 | 3045 | 84 | 12180 | 9.45 | 240 | 1.30 |
| RS9-16 | 25 | 1 | 25.0 | 26.4 | 34.5 | 36.1 | 38.5 | 40.9 | 40.5 | 21 | 3045 | 84 | 12180 | 11.81 | 300 | 1.70 |
| RS9-20 | 31.5 | 1 1/4 | 31.4 | 33.0 | 43.3 | 45.6 | 49.2 | 52.4 | 50.7 | 17.5 | 2540 | 70 | 10150 | 16.54 | 420 | 3.08 |
| RS9-24 | 38 | 1 1/2 | 37.7 | 39.3 | 49.6 | 52.0 | 55.6 | 58.7 | 147 | 2030 | 56 | 8120 | 19.69 | 500 | 4.30 | |
| RS9-32 | 51 | 2 | 50.4 | 52.0 | 63.9 | 66.2 | 69.9 | 73.0 | 14 | 2030 | 56 | 8120 | 25.98 | 660 | 5.63 | |
