100w double glass thin film solar panel for architecture
- 1000000 Kilowatt / Kilowatts per Month
- Tianjin/Qingdao
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
Durable high quality duoble glass 100w thin film solar panel
-
250W High Grade CIGS Thin Film Flexible Roofing Solar Panel
-
High performance 250w cigs flexible thin film solar module, flexible solar panel
-
90W High Grade CIGS Thin Film Flexible Solar Panel for Roofing and Carport
-
High performance cigs flexible thin film solar module, flexible solar panel
-
Durable high grade 250W CIGS Solar Panel for home use
Product Details
Place of Origin | Hebei, China | Brand Name | OEM/FR | |
Model Number | FR-TH-100W | Material | Amorphous Silicon | |
Size | 1300*1100*7.9mm | Max. Power | 100W |
Product Description
100w double glass thin film solar panel for architecture
Maximum Power(W) | 100 W | ||||||
Optimum Power Voltage(Vmp) | 96.29V | ||||||
Optimum Operatige Current(Imp) | 1.28A | ||||||
Open Circuit Voltage(Voc) | 120.38V | ||||||
Short Circuit Current(Isc) | 1.44 A | ||||||
Size of Module(mm) | 1300*1100*7.9MM | ||||||
Tolerance (WP) | ±3% | ||||||
NOCT | 45±3 °C | ||||||
Power Temp. Coeff(/°C) | -0.27% | ||||||
Current Temp. Coeff(/°C) | 0.05% | ||||||
Voltage Temp. Coeff(/°C) | -0.31% | ||||||
Cell Type | a-Si solar module | ||||||
Module Efficiency (%) | 7% | ||||||
Warranty | 90% of 10 years,80% of 20 years. | ||||||
Standard Test Conditions | AM1.5 1000W/m2 25 +/-2°C | ||||||
Weight | 26.5kg |
1. Reply your inquiry in 12 working hours
2. Customized design is available, OEM is welcomed
Q: How to palce an order after choosing the products?
A: Please contact our customer service representative for details.
Q: Can you accept OEM service?
A: Yes, we can. Qty is not the only standard, more quality, less cost.
Q: How about your after sales-service?
A: 10 years limited warranty on material and workmanship,
12 years warranty on power output to not fall below 90%,
25 years warranty on power output to not fall below 80%.
Q: How about your payment terms?
A: We accept T/T, Western Union, Money Gram, L/C.
Q: What certification do you have?
A: We have CE/IEC/CSA/CQC/CEC or According to your need, if you place an big order.
How do solar panel work?
PV cells are made from layers of semi-conducting material, usually silicon. When light shines on the cell it creates an electric field across the layers. The stronger the sunshine, the more electricity is produced. Groups of cells are mounted together in panels or modules that can either be mounted on your roof or on the ground.
The power of a PV cell is measured in kilowatts peak (kWp). That's the rate at which it generates energy at peak performance in full direct sunlight during the summer. PV cells come in a variety of shapes and sizes. Most PV systems are made up of panels that fit on top of an existing roof, but you can also fit solar tiles.
