Best value for waste recycle . waste tire/rubber pyrolysis plant to fuel oil in thailand market.

Specifications

waste tire recycling production line by pyrolysis technology

1.Several characteristics of the streamlined series refining equipment

1.Each set of equipment is commposed by ten parts.

  a.Mine engine horizontal type revoving split processor.

  b.Horizontal-fixed disillation processor.

  c.Feeding-in system.

  d.Tapping system.

  e.Central electrically controlled system

  f.Condensation system

 g.Every oil refining system

 h.Fuel gas heating system (waste gas processing system)

 i.Waste water processing system.

 j.Fuel dust removal system.

 2. Domestic pioneer of this technology

a. In its key installment decomposition processor design, has thoroughly overcome the disadvantages of the domestic present vertical flat base split processor, such as bottom partial being heated non-uniformity, easy to break, low output, short service-life is short and so on, the main engine uses horizontal-type 360o structure-0.4 R/M.

b. Fast practical feed-in and discharge system. The highest feed-in quantity of the XY-5 every 24 hour achieved 5 tons, Discharge time for 300kg carbon black only needs 90 minutes. The highest feed-in amount of the integral unit equipment every 24 hours achieves 15 tons.

c. Highly effectively gas heating system. In the process of refining oil, after the gas is heated up to 150 , it will produce a large amount of unliquefied gas-CH4& C4H8 ,? which cant be formed at normal temperature, normal pressure. ?If those gases have been fully burning by the specific designed gas nozzle, they can produce a great amount of energy and economize resources. Take the bunker coal as the example, when there is no fuel gas as combustion-supporting for the equipment, every 24 hours need 1.2 tons coals. After the fuel gas aid combustion, every 24 hour need 0.3 tons coal, which enhances production efficiency in the large scale and reduced the fuel cost?

d. Flue dust catcher system. It matches the bidirectional water impact type tornado dust removal room, and the rate of the flue dust catch is access than 95% .

3.Machinery Technical parameter:

4.Machinery parts picture show:

5.The certificate we got :
