Home > Products > Slewing Bearing > Slewing Bearing
Slewing Bearing
- Qingdao Port
- T/T Credit Card
You May Like
Product Details
| Brand Name | OEM | Bore Size | 760, 1525 | |
| Outside Diameter | 1000, 1875 | Model Number | 010 Series | |
| Feature | Cross Roller | Gear Options | Nongeared | |
| Seals Type | Open | Place of Origin | Sweden |
Product Description
Specifications
Slewing BearingsResistance to High Temperature
Standard Export Package
Long Service Life
ISO9001:2008
Slewing bearings
Resistance to High Temperature
Standard Export Package
Long Service Life
ISO9001:2008
Slewing bearings
ball bearing,roller bearing,with internal tooth type,tooth type,with sealed and other structure,can bear joint load,and can bear large overturning moment,bearing precision rotary gear accuracy is very high.
Bearing No. | Dimension | Gear Parameter | Weight(KG) | |||||||
D | dn | H | h | L | da | m | z | x |
| |
HSW880.32 | 1000 | 760 | 95 | 12 | 70 | 1047.5 | 8 | 127 | 1.15 | 240 |
HSW1020.32 | 1170 | 875 | 95 | 15 | 70 | 1219.3 | 8 | 148 | 1.4 | 320 |
HSW1220.40 | 1365 | 1075 | 120 | 15 | 90 | 1424.91 | 10 | 138 | 1.4 | 463 |
HSW1250.40 | 1400 | 1090 | 120 | 15 | 90 | 1457.94 | 10 | 142 | 1 | 480 |
HSW1250.40A | 90 | 1455.17 | 12 | 118 | 1 | |||||
HSW1435.40 | 1595 | 1278 | 120 | 15 | 90 | 1655.46 | 12 | 134 | 1.15 | 577 |
HSW1435.40A | 90 | 1661.17 | 14 | 115 | 1 | |||||
HSW1540.50 | 1720 | 1360 | 140 | 18 | 110 | 1780.8 | 12 | 144 | 1.4 | 864 |
HSW1540.50A | 110 | 1791.1 | 14 | 124 | 1.15 | |||||
HSW1700.50 | 1875 | 1525 | 140 | 18 | 110 | 1945.4 | 14 | 135 | 1.15 | 883 |
HSW1700.50A | 110 | 1950.8 | 16 | 118 | 1.15 | |||||
HSN880.32 | 1000 | 760 | 95 | 12.5 | 70 | 718.18 | 8 | 91 | 0.35 | 230 |
Slewing bearings
used in cranes,mining machinery,construction machinery,port machinery.
