Customzied PCBA circuit board / Pcb Assembly

FOB Price

US$ 0.2 - 20 / Piece

10 Pieces(Min. Order)

Port shenzhen
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China	Brand Name	zxb PCBA
Model Number	Pcba Assembly	Base Material	FR-4
Copper Thickness	1oz-12oz	Board Thickness	0.2-3.0mm
Min. Hole Size	0.20mm	Min. Line Width	0.075mm/0.1mm(3mil/4mil)
Min. Line Spacing	0.075mm=3mil	Surface Finishing	HASL lead free

Product Description

Customzied PCBA circuit board / Pcb Assembly

Description

1. Single sided PCB, double sided PCB & multilayer PCB with competitive price, good quality and excellent service.

2. FR-4, FR-4 High TG, CEM-1, CEM-3, Aluminum base material.

3. HAL, HAL lead free, Immersion Gold/ Silver/Tin, OSP surface treatment.

4. Printed Circuit Boards are 94V0 compliant, and adhere to IPC610 Class 2 international PCB standard.

5. Quantities range from prototype to medium and batch production.

Item	Capability
PCB Layers	1-24 Layers
Base Material	FR4,CEM1,CEM3,ALU,FR2,FR1,Polymide,Rogers,Arlon,Teflon
Copper Thickness	0.5-6 OZ
Impedance Control	Yes
Peeable Mask	Yes
Min.Line Width	0.75mm
Min.Line Spacing	0.75mm
Min.Annual Ring PTH	0.15mm
PTH	0.20mm±0.05mm
Non-PTH	0.15mm±0.05mm
Hole Aspect Ratio	10
Min.Board Thickness	Singel&Double side 0.2mm
Min.Board Thickness	Multilayer(4,6,8,10 layer)0.4mm,0.55mm,0.8mm,0,8mm
Max Board Sixe	600900mm,4001200mm
Solder Mask Pitch	0.1mm
Outline Tolerance	±0.15mm
V-CUT Tolerance	±0.10mm
thickness Tolerance	MIL-P-13949 Class 2
Gold Finger	5u"-50u"
Surface Finish	HASL,LF HAL,Immersion Gold,Immersion silver,Flash Gold,Flux Coat&OSP
Special Capability	Burial/blind vias,Impedance Control,via plug,BGA,Gold Finger
Test	Fly probe test,E-test,Inspection AOI test
Certificate	RoHS,ISO9001:2000,ISO14001:2004,SGS,UL

PCB assembly capability and services

1. Single-sided, double side & multi-layer PCB. FPC. Flex Rigid PCB with competitive price,

good quality and excellent service.

2. CEM-1, CEM-3 FR-4, FR-4 High TG, Aluminum base material, Polyimide, etc.

3. HAL, HAL lead free, Immersion Gold/ Silver/Tin, OSP surface treatment.

4. Quantities range from sample to mass order<

5. 100% E-Test
