Home > Products > Stacker > 9t Container Lift Stacker

9t Container Lift Stacker

FOB Price

Negotiable / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

9t Container Lift Stacker reach stacker
CAN-bus electronic control system, engine and gearbox is controled by electronic unit

9t Container Lift Stacker

LG260EC7 Stacker

Machine to configure high-intensity wide-view door frame, door frame with two type,

Drive axle with heavy-duty vehicles produced in Germany KESSLER drive axle.

Transmission using the U.S. DANA Corporation TE-17000-type gearbox,

Using the Swedish VOLVO TAD 720VE engine,

Equipped with the world's most advanced variable piston pump and load-sensing valve load sensing system

Equipped with box-type chassis, frame body as the car beam welded structure, hydraulic tank and fuel tank

CAN-bus electronic control system, engine and gearbox is equipped with electronic control unit,

Equipped with an advanced user-friendly spacious cab, window glass, using large circular front corner

MODEL		LG260EC7
Mast Height Raised (Overall Height)	mm	19430
Mast Height Lowered	mm	10760
Fork length	mm
Overall Length(With Attachments)	mm	6655
Overall Width(Without Attachments)	mm	4060
Attachment Width	mm	60381/12165
Overall Height(Overhead Guard)	mm	3900
Wheel Base	mm	4500
Front Thread	mm	3270
Rear Thread	mm	2330
Min. Turning Radius	mm	6000
Min. Intersecting Aisle	mm	8100
Overhead Guard Clearance (From face of seat)	mm	1200
Attachment Height	mm	2675
Traction Pin Height	mm	630
Rear Overhang	mm	960
Tilting Angle	°	2/4

SPECIFICATION

MODEL		LG260EC7
Load Capacity	kg	9000
Load Center	mm	1220
Power Type		Diesel
Tire Type		Pneumatic
Lifting Speed(With Load/Without Load)	mm/s	630/730
Down Speed(With Load)	mm/s	600
Travel Speed(With Load)	km/h	30
Max. Gradeability	%	28
Wheel(Front/Rear)		4/2
Tire(Front/Rear)		14.00*24-28PR
Wheel With Load(Front/Rear)	kg	40700/8300
Wheel Without Load(Front/Rear)	kg	27700/12300
Service Brake		QIL-COOLED DISC
Parking Brake		Caliper Disc
Engine Model		VOLVO TAD 720VE
Fuel Tank Capacity, Engine	L	400
Operation Weight	kg	41500

20-40 feet empty container spreader with telescopic spreader
